Summary of Contents for IKEA SMAKSAK

  • Page 1 SMAKSAK...
  • Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Before first use Energy efficiency Daily use Environmental concerns Clock functions IKEA guarantee Using the accessories Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage.
  • Page 5 ENGLISH WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down. If the appliance has a child safety device, it should be • activated.

  • Page 6: Safety Instructions

    ENGLISH Safety instructions Installation Ventilation opening 560x20 mm Warning! Only a qualified person minimum size. Open‐ must install this appliance. ing placed on the bot‐ tom rear side • Remove all the packaging. • Do not install or use a damaged Mains supply cable 1500 mm appliance.
  • Page 7 ENGLISH • Do not pull the mains cable to disconnect – do not put water directly into the hot the appliance. Always pull the mains plug. appliance. • Use only correct isolation devices: line – do not keep moist dishes and food in protecting cut-outs, fuses (screw type the appliance after you finish the fuses removed from the holder), earth...

  • Page 8: Installation

    ENGLISH Internal lighting • Use original spare parts only. Warning! Risk of electric shock. Disposal Warning! Risk of injury or • Concerning the lamp(s) inside this suffocation. product and spare part lamps sold separately: These lamps are intended to • Disconnect the appliance from the mains withstand extreme physical conditions in supply.

  • Page 9: Product Description

    ENGLISH Product description General overview Control panel Knob for the heating functions Display Control knob Heating element Lamp Cavity embossment Shelf support, removable Rating plate Shelf positions Accessories • Grill- / Roasting pan x 1 To bake and roast or as pan to collect fat. •...

  • Page 10: Before First Use

    ENGLISH Display A. Timer / Temperature B. Heat-up and residual heat indicator C. Core temperature sensor (selected models only) D. Door lock (selected models only) E. Hours / minutes F. Demo mode (selected models only) G. Clock functions Before first use Using the Mechanical child lock Warning! Refer to Safety chapters.

  • Page 11: Daily Use

    ENGLISH Warning! Be careful not to scratch the control panel. Daily use Warning! Refer to Safety Heating Application chapters. function Heating functions To bake pizza. To make inten‐ sive browning and a crispy bottom. Heating Application Bread and function Pizza Bak‐ The oven is off.
  • Page 12 ENGLISH Setting the function: Direct Steam Heating Application This function increases humidity during function cooking. This function is designed to save energy during cooking. Warning! Risk of burns and For the cooking instructions damage to the appliance. Eco Fan refer to "Hints and tips" chap‐ Cooking Released humidity can cause burns.

  • Page 13: Clock Functions

    ENGLISH Heat-up indicator the temperature in the oven increases, and disappear when it decreases. When the oven function operates, the bars in the display appear one by one when Clock functions Clock functions table Setting and changing the time After the first connection to the mains, wait Clock function Application until the display shows...

  • Page 14: Using The Accessories

    ENGLISH Setting the END function At the set END time the signal sounds for 2 minutes. and time setting flash in the 1. Set a heating function. Press display. The oven turns off. confirm. 5. Press any button to stop the signal. 2.
  • Page 15 ENGLISH Push the shelf between the guide bars of the Small indentation at the top shelf support and make sure that the feet increase safety. The indentations point down. are also anti-tip devices. The high rim around the shelf prevents cookware from slipping of the shelf.

  • Page 16: Additional Functions

    ENGLISH Additional functions Using the Child Lock Temperature (°C) Switch-off time (h) When the Child Lock is on the oven cannot 120 - 195 be turned on accidentally. 200 - 245 1. Ensure the knob for the oven functions is in the off position.
  • Page 17 ENGLISH If you use two baking trays at the same time, Initially, monitor the performance when you keep one empty level between them. cook. Find the best settings (heat setting, cooking time, etc.) for your cookware, Cooking meat and fish recipes and quantities when you use this Use a deep pan for very fatty food to prevent appliance.
  • Page 18 ENGLISH Food Accessories Temperature Shelf posi‐ Time (min) (°C) tion Fish fillet, 0.3 kg pizza pan on wire shelf 25 - 30 Poached meat, baking tray or dripping 35 - 45 0.25 kg Shashlik, 0.5 kg baking tray or dripping 25 - 30 Cookies, 16 baking tray or dripping...
  • Page 19 ENGLISH Accessories Size Picture Pizza pan, dark, non-reflec‐ 28 cm diameter tive Baking dish, dark, non-re‐ 26 cm diameter flective Ramekins, ceramic 8 cm diameter, 5 cm height Flan base tin, dark, non-re‐ 28 cm diameter flective Information for test institutes Tests according to IEC 60350-1.
  • Page 20 ENGLISH Food Function Accesso‐ Shelf Temper‐ Time (min) Comments ries posi‐ ature tion (°C) Apple pie Forced Air Wire shelf 2 70 - 90 Use 2 tins (20 cm Cooking diameter), diago‐ nally shifted. Fatless‐ Convention‐ Wire shelf 2 40 - 50 Use a cake mould ponge al (Top and...

  • Page 21: Care And Cleaning

    For additional cooking tables please refer to cavity. the Recipe Book which you can find on the website www.ikea.com. To find the proper Care and cleaning Warning! Refer to Safety chapters.
  • Page 22 ENGLISH To clean the oven, remove the shelf supports. 1. Pull carefully the supports up and out of the front catch. 3. Close the oven door halfway to the first opening position. Then lift and pull forward and remove the door from its seat.
  • Page 23 ENGLISH 8. Clean the glass panels with water and soap. Dry the glass panels carefully. Do not clean the glass panels in the dishwasher. When the cleaning is completed, install the glass panels, the door trim and the oven door, close the levers on the both hinges. Make sure that you put the glass panels (A and B) back in the correct sequence.

  • Page 24: Troubleshooting

    ENGLISH Step 3 Replace the lamp with a suitable 300 °C heat-resistant lamp. Step 4 Install the glass cover. Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Remedy The oven does not heat up. The oven is deactivated. Activate the oven.

  • Page 25: Technical Data

    ENGLISH Problem Possible cause Remedy There is no good cooking You did not turn on the func‐ Refer to "Activating the func‐ performance using the func‐ tion: Direct Steam. tion: Direct Steam". tion: Direct Steam. There is no good cooking You did not fill the cavity em‐...

  • Page 26: Energy Efficiency

    Frequency 50 - 60 Hz Number of functions Energy efficiency Product Information and Product Information Sheet* Supplier's name IKEA SMAKSAK 204.118.78 Model identification SMAKSAK 604.118.57 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, convention‐ 0.93 kWh/cycle...

  • Page 27: Environmental Concerns

    ENGLISH * For European Union according to EU Regulations 65/2014 and 66/2014. For Republic of Belarus according to STB 2478-2017, Appendix G; STB 2477-2017, Annexes A and B. For Ukraine according to 568/32020. Energy efficiency class is not applicable for Russia. EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance.

  • Page 28: Ikea Guarantee

    IKEA. The original sales receipt is required including but not limited to damage as proof of purchase. If service work is...
  • Page 29 The IKEA guarantee gives you specific legal Please refer to the last page of this manual rights, which covers or exceed local for the full list of IKEA appointed contacts demands. However these conditions do not and relative national phone numbers.
  • Page 30 Magyarország 06-1-252-1773 Belföldi díjszabás Hétköznap 8.00 és 17.00 óra között 050-7111267 ma-vr: 8.00 - 21.00 Nederland Geen extra kosten. (0900-BEL IKEA) zat: 9.00 - 21.00 Luxembourg +31 507111267 Alleen lokaal tarief. zon / pub. vakantie: 10.00 - 18.00 (internationaal) Norge l i t Österreich...
  • Page 32 21552 © Inter IKEA Systems B.V. 2022 AA-2048960-5...
