IKEA SMAKSAK Manual

Hide thumbs Also See for SMAKSAK:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Manual
AU
SMAKSAK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMAKSAK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IKEA SMAKSAK

Summary of Contents for IKEA SMAKSAK

  • Page 1 SMAKSAK...
  • Page 2 ENGLISH Please refer to the chapter IKEA GUARANTEE for contact details of the after sales customer service centre.
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Control panel Technical data Before first use Environmental concerns Daily use IKEA guarantee Clock functions Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages.
  • Page 5 ENGLISH Keep children and pets away from the appliance when it • operates or when it cools down. Accessible parts are hot. If the appliance has a child safety device, it should be • activated. Children shall not carry out cleaning and user maintenance of •...
  • Page 6 ENGLISH Do not heat liquids and other foods in sealed containers. • They are liable to explode. Metallic containers for food and beverages are not allowed • during microwave cooking. This requirement is not applicable if the manufacturer specifies size and shape of metallic containers suitable for microwave cooking.

  • Page 7: Conditions Of Use

    ENGLISH Conditions of Use • By clients in serviced apartments, holiday This appliance is intended to be used in apartments and other residential type household and similar applications such as: environments. • Farm houses Safety instructions Should the mains cable need to be Installation replaced, this must be carried out by our Warning! Only a qualified...
  • Page 8 ENGLISH • Do not let the appliance stay unattended • If the appliance is installed behind a during operation. furniture panel (e.g. a door) make sure • Deactivate the appliance after each use. the door is never closed when the •...

  • Page 9: Installation

    ENGLISH pieces may be extremely sharp and appliances only. Do not use it for house difficult to locate. lighting. • Do not place hot glassware on a wet or • Before replacing the lamp, disconnect cool surface, directly on countertop or the appliance from the power supply.

  • Page 10: Product Description

    ENGLISH This oven is only supplied with a main Total power (W) Section of the cable cable. (mm²) Cable maximum 1380 3 x 0.75 Cable types applicable for installation or maximum 2300 3 x 1 replacement: maximum 3680 3 x 1.5 H07 RN-F, H05 RN-F, H05 RRF, H05 VV-F, H05 V2V2-F (T90), H05 BB-F The earth cord (green / yellow cable) must...

  • Page 11: Control Panel

    ENGLISH Control panel Buttons Sensor field / Button Function Description OPTIONS To set the clock functions, microwave power. To check the oven temperature. Use only while a heating function oper- ates. START + 30sec To start a heating function. Press to ex- tend Microwave function duration for 30 seconds.

  • Page 12: Daily Use

    ENGLISH 1. Pull and hold the child lock handle up as microwave bottom glass plate must be shown in the picture. removed. 1. Set the function and the maximum temperature. 2. Let the oven operate for 1 hour. 3. Set the function and set the maximum temperature.
  • Page 13 ENGLISH Heating Application Heating Application function function Microwave Combi - function Microwave function at medi- with MW boost that acceler- um power (300 - 700 W). ates cooking. To heat pre-prepared meals. Conven- Reheating To bake and roast food on Creates the heat directly in tional one shelf position.

  • Page 14: Clock Functions

    ENGLISH temperature. Turn the control knob to 4. Press again and again to change: Duration and microwave power. Turn set the value and press to confirm. the control knob to set the value and Around 5 degrees before the set temperature is reached the signal press to confirm.You can also press...
  • Page 15 ENGLISH Setting the DURATION function Clock function Application 1. Set a heating function. Press Use to set a countdown confirm. time. This function has no MINUTE 2. Press again and again until effect on the operation of MINDER starts to flash. the oven.

  • Page 16: Using The Accessories

    ENGLISH 3. Turn the control knob to set the minutes Setting the MINUTE MINDER for DURATION time and press Minute minder can be both set when the confirm. Turn the control knob to set the oven is turned on and off. hours for DURATION time and press 1.

  • Page 17: Additional Functions

    ENGLISH Put the accessory on the bottom of the cavity. Put the food on the microwave bottom glass plate. Always use the microwave bottom glass plate when the microwave function is on. It is necessary for heating food or liquids. Warning! The microwave bottom glass plate can become hot when Wire shelf and baking tray together:...

  • Page 18: Hints And Tips

    ENGLISH Residual heat indicator The Automatic switch-off does not work with the functions: Light, When you turn off the oven, the display Duration, End. shows the residual heat indicator if the temperature in the oven is more than 40 Cooling fan °C.Turn the control knob left or right to When the oven operates, the cooling fan check the oven temperature.
  • Page 19 ENGLISH Microwave cooking To prevent too much smoke in the oven Cook food covered. If you want to keep a during roasting, add some water into the crust cook food without a cover. deep pan. To prevent the smoke condensation, add water each time after it Do not overcook the dishes by setting the dries up.
  • Page 20 ENGLISH Cookware / Material Microwave function Microwave Combi Defrosting Heating, Cooking function e.g. Non-ovenproof glass and porcelain without any silver, gold, platinum or other metal decorations Glass and glass ceramic made of ovenproof / frost-proof material Ceramic and earthenware without any quartz or metal components and glazes which contain metal Ceramic, porcelain and earthenware...
  • Page 21 ENGLISH Microwave defrosting Food Power (Watts) Time (min) Standing time (min) Steak (0.2 kg) 5 - 7 5 - 10 Minced meat (0.5 kg) 8 - 12 5 - 10 Chicken (1 kg) 30 - 35 10 - 20 Chicken breast (0.15 kg) 5 - 9 10 - 15 Chicken legs (0.15 kg)
  • Page 22 ENGLISH Food Power (Watts) Time (min) Standing time (min) Convenience food (0.5 6 - 9 2 - 5 Frozen ready meals (0.5 10 - 15 2 - 5 Milk (200 ml) 1000 1 - 1:30 Water (200 ml) 1000 1:30 - 2 Sauce (200 ml) 1 - 3 Soup (300 ml)
  • Page 23 ENGLISH Microwave Combi function Use this function to cook food in a shorter time and to brown it. Food Function Power Tempera- Time Shelf Comments (Watts ture (°C) (min) posi- tion Potato Grilling + MW 180 - 190 40 - 45 Turn the container Gratin (1.1 around halfway...
  • Page 24 ENGLISH Cooking/Defrosting Possible cause Remedy results The food is still not The time was too short. Set a longer time. Do not increase the defrosted, hot or microwave power. cooked after the end of cooking time. The food is overhea- The power was too high.
  • Page 25 ENGLISH Power setting • 1000 Watt Heating liquids • 900 Watt Searing at the start of the cooking process • 800 Watt Cooking vegetables • 700 Watt • 600 Watt Defrosting and heating frozen meals • 500 Watt Heating one-plate meals Simmering stews Cooking egg dishes •...

  • Page 26: Care And Cleaning

    ENGLISH Food Power Quantity Shelf posi- Time (min) Comments (Watts) (kg) tion Meat de- Bottom 8 - 12 Turn the meat upside frosting down halfway through the cooking time. 1) Use wire shelf unless otherwise specified. Microwave Combi function Tests according to IEC 60705. Food Function Power...
  • Page 27 ENGLISH Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a cleaning agent. Do not clean the accessories in the dishwasher. Clean stubborn dirt with a special oven cleaner. If you have nonstick accessories, do not clean them using aggressive agents, sharp- 2.

  • Page 28: Troubleshooting

    ENGLISH Troubleshooting Warning! Refer to Safety chapters. What to do if... Problem Possible cause Remedy The oven does not heat up. The oven is deactivated. Activate the oven. The oven does not heat up. The clock is not set. Set the clock. The oven does not heat up.

  • Page 29: Technical Data

    ENGLISH the front frame of the oven cavity. Do not Service data remove the rating plate from the oven If you cannot find a solution to the problem cavity. yourself, contact an Authorised Service Centre. The necessary data for the service centre is on the rating plate.

  • Page 30: Environmental Concerns

    IKEA Service Office original date of purchase of Your appliance L1 Clock Tower, 630 Princes Highway at IKEA Pty Ltd, ABN 84006270757 or at Tempe, NSW 2044 Cebas Pty Ltd, ABN 15 009 156 003 (Both Trading as IKEA). The original sales receipt Contact - IKEA Customer Service at is required as proof of purchase.
  • Page 31 • Repairs not carried out by our appointed Australia. service providers and/or an authorized What will IKEA do to correct the problem? service contractual partner or where non-original parts have been used. IKEA appointed service provider will exam- •...
  • Page 32 Our goods come with guarantees that 3. Ask for clarification on user manual con- cannot be excluded under the Australian tents and specifications of the IKEA ap- Consumer Law (ACL). You are entitled to a pliance. replacement or refund for a major failure...
  • Page 33 It is your proof of purchase and required for the guarantee to apply. Note that the receipt reports also the IKEA article name and number (8 digit code) for each of the appliances you have purchased.
  • Page 34 ENGLISH...
  • Page 35 ENGLISH...
  • Page 36 21552 © Inter IKEA Systems B.V. 2018 AA-2048717-1...
