9. Checking the resolution change IC movement

Is there +3.3V supply on U3 pins 65, 76, 86, 121, 143, 157, 167, 198, 193, 183, 179, 175, 188.

Is there +2.5V supply on U3 pins 5, 7, 10, 11, 12, 15, 18, 21, 22, 25, 28, 31, 35, 36, 42, 63, 76,

88, 119, 141, 159, 162, 163, 166, 169, 170, 189, 190, 196.

Is 14.318MHz clock input to U3 pin 3, 4 at

TTL level.?

Is 14.318MHz clock output from Y1 at TTL

level.?

Proceed section 11 "Checking the

operation of CPU"

All manuals and user guides at all-guides.com

Failure point

Y1 failure

6-14

Proceed section 11 "Checking the

operation of CPU"
