Connector cover

Cable cover

Clip B

Figure C.1

Vacation Switch

Power Button

Figure D.1

Tilt

Grasp both sides of the monitor screen with your hands and adjust the

tilt as desired (Figure TS.1).

Remove Monitor Stand for Mounting

To prepare the monitor for alternate mounting purposes:

1. Remove the connector cover and cable cover (Figure R.1).

2. Disconnect all cables.

3. Place monitor face down on a non-abrasive surface (Figure R.2).

English-5
