10. No power on
Check the +12V power provided from SW REG
board.
NG
Check the +5V power from SW REG board.
OK
NG
Is LED turned on in amber momentarily when
power button is pushed.
OK
NG
Proceed section 11 "Checking the operation of
CPU".
OK
All manuals and user guides at all-guides.com
SW REG board failure.
6-15
Failure point
SW REG board failure.
Failure point
SW REG board failure.
Failure point
