NEC MultiSync LCD1550V Service Manual page 76

SYMBOL Part No for Compal Part No forNMV
SW8 DE611001500
*** PWB ASSYS ***
CTRLBD 461A7367004
INVBD 453A7567001
KEYBD 454A5267001
POWBD 453A7367001
*** COILS & FILTERS ***
CORE DC150010200
L1 SM010014200
L12 SM060000500
L13 SM010006300
L2 SM010014200
L22 SM010007200
L3 SM010014200
L4 SM010007200
L5 SM010007200
L6 SM010007200
L7 SM010007200
L8 SM010007200
L801 CL900006805
L802 CL900006805
L803 DC1510009T0
L841 CL300003600
L842 CL300003600
L9 SM010006300
L911 CL310011600
L951 CL310011600
*** ELECTRICAL PARTS & MISCELLANEOUS PARTS ***
CABLAS DC190020600
CABLCT DC020145400
CABLSW DC020149900
CN2 SP02E002100
CN3 SP02E002100
F801 DX202P02135
F901 SP0402P3000
FFC NBX40000300
P801 DC040011700
PWRC GA020000160
VA801 DC350001700
Y1 BD114P3M010
LCD AC600022900
*** APPEARANCE PARTS ***
BASE FANM5517100
CABB FANM5516100
All manuals and user guides at all-guides.com
79PP0615
79PP0860
79PP0802
79PP0584
79PP0801
79PP0807
79PP0491
79PP0668
79PP0447
79PP0491
79PP0136
79PP0491
79PP0136
79PP0136
79PP0136
79PP0136
79PP0136
79PP0769
79PP0769
79PP5278
79PP0768
79PP0768
79PP0447
79PP0613
79PP0613
79PP0614
79PP0699
79PP0806
79PP0670
79PP0670
79PP0772
79PP0830
79PP0808
79PP0791
79PP0674
79PP0770
79PP0610
79PP0804
79PP0618
79PP0587
8-3
DESCRIPTION
TACT SW NM555 SKHHBW2720
FIRMWARE CTRL/B VL-543 LN
PCBA INVERTER/B VI-543 LN
PCBA KEY/B VK-530 LNM555G
PCBA POWER/B VP-543 LNS55
CORE KC K5B FS 25.5X4.5X
SSUPPRE KC FBM-L11-160808
SUPPRE NWE STC222B
CHIP MURATA BLM21P300S
SSUPPRE KC FBM-L11-160808
COIL BLM21P221SG
SSUPPRE KC FBM-L11-160808
COIL BLM21P221SG
COIL BLM21P221SG
COIL BLM21P221SG
COIL BLM21P221SG
COIL BLM21P221SG
LINE FILT BJ350 5MH 1.2A
LINE FILT BJ350 5MH 1.2A
BEAD NWE W5 3.5X6X1.0+T
CHOK COIL NM555 2.9UH +-3
CHOK COIL NM555 2.9UH +-3
CHIP MURATA BLM21P300S
CHOK COIL NM555 245UH K
CHOK COIL NM555 245UH K
CB ASY NM555 20276/2CORE
H-CON SET NM555 CTRL-KEY
H-CON SET NS555 P802-SW
W-CONN E&T 98210-4011 40P
W-CONN E&T 98210-4011 40P
FUSE 2AH 250V S UL/SENKO/
S FUSE 2.3A 50V UL/CSA FA
FFC 40P G P0.5 PAD=0.5 71
SOCKET POWER SA-4S-066
PWR CORD SP022X2.0MXIS14
ABSORBER PANASONIC ERVZ07
CRYSTAL 14.31818MHZ HC-49
LCD HSD150SX84-B 15" HANNSTAR
BASE ASSY NM5517 ABS+PC M
CABINET BACK ASSY
