B. Installing the TMA 1600-III
1. Check to make sure that the scanner power is switched off.
2. Remove the scanner lid, then attach the TMA 1600-III by sliding the posts at the
3. Plug the connector of the TMA 1600-
6 ScanMaker 9800XL Plus User Guide
rear of the TMA 1600-III into the holes.
III into the scanner's 15-pin
accessory port.
Scanner lid
TMA 1600-III
