The expansion board is delivered with a cover glass holder in which you can fit three different spacers of 0.25, 0.5, and 1 mm height below the cover glass to simulate various air gaps. A small oval cover glass fitting the sensor is included. Several ST expansion boards can be stacked through the Arduino connectors, which allow, for example, the development of VL53L4CX applications with Bluetooth or Wi-Fi interfaces.
Getting started Getting started Safety considerations 1.1.1 Electrostatic precautions Warning: Take electrostatic precautions, including ground straps, when using the X-NUCLEO-53L4A2 expansion board. Failure to prevent electrostatic discharge could damage the device. Figure 2. Electrostatic logo 1.1.2 Laser safety considerations VL53L4CX contains a laser emitter and the corresponding drive circuitry.
UM2976 Spacers and covers Spacers and covers X-NUCLEO-53L4A2 expansion board is delivered with: • three spacers of 0.25 mm, 0.5 mm, and 1 mm height, used to simulate different air gaps between the VL53L4CX and the rectangular-shaped cover glass; •...
UM2976 Using the expansion board Using the expansion board X-NUCLEO-53L4A2 expansion board allows the user to test the VL53L4CX sensor functionality, to program it and to understand how to develop an application using this sensor. X-NUCLEO-53L4A2 integrates: • VL53L4CX sensor;...
UM2976 Breakout boards Breakout boards X-NUCLEO-53L4A2 package does not include the VL53L4CX breakout boards. You can purchase them in a pack of two PCBs as SATEL-VL53L4CX. X-NUCLEO-53L4A2 supplies the VL53L4CX breakout boards at 3.3 V (see Figure For mechanical integration purposes, it could be interesting to use the mini PCB by breaking the...
UM2976 Graphical user interface (GUI) and programming example for the X-NUCLEO-53L4A2 Graphical user interface (GUI) and programming example for the X-NUCLEO-53L4A2 To evaluate the VL53L4CX device performance, use the related GUI or the X-CUBE-TOF1. X-NUCLEO-53L4A2 expansion board requires the NUCLEO-F401RE development board to use the GUI or run the ranging examples included in the X-CUBE-TOF1.
UM2976 Schematic diagrams Schematic diagrams Figure 8. X-NUCLEO-53L4A2 circuit schematic (1 of 6) 2.2k 2.2k Host.SchDoc Sensor.SchDoc XSHUT GPIO1 Right Satellite Connector.SchDoc XSHUT PA10 GPIO1 Left Satellite Connector.SchDoc PB10 XSHUT GPIO1 Display Connector.SchDoc 2.2k 2.2k LCD_SCL LCD_SDA Note: The display connector is an optional connector to connect an SSD1306 I2C OLED display to output the ranging data or other meaningful information if required.
UM2976 Bill of materials Bill of materials Table 1. X-NUCLEO-53L4A2 bill of materials Item Quantity Reference Part/value Description Manufacturer Order code 4-position, SNGL, Connector header Samtec SSW-104-01-G-S 4x1, 2.54 mm, T/H (not mounted) 4.7 µF, 6.3 V, X5R, Ceramic capacitor...
UM2976 Board versions Board versions Table 2. X-NUCLEO-53L4A2 versions Finished good Schematic diagrams Bill of materials XNUCLEO$53L4A2A XNUCLEO$53L4A2A schematic diagrams XNUCLEO$53L4A2A bill of materials 1. This code identifies the X-NUCLEO-53L4A2 evaluation board first version. UM2976 - Rev 1 page 15/22...
UM2976 Regulatory compliance information Regulatory compliance information Formal Notice Required by the U.S. Federal Communications Commission FCC NOTICE: This kit is designed to allow: (1) Product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and (2) Software developers to write software applications for use with the end product.
Page 22
ST’s terms and conditions of sale in place at the time of order acknowledgement. Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of Purchasers’...
