Replacing Air Tubing Section 5-Repair Procedures
Replacing Cables
If you suspect a cable to be faulty, check its continuity on all pins. If you need to replace a cable,
refer to Section 7 for part numbers. See the figure on page 90 for cable locations.
When removing a cable, be sure to note the routing. It is important that the new cable is routed in
the same manner.
P11
P9
P1
P8
P10
P5
P6
0696-37
P7
