- Page 1 PocketScopes ™ Otoscope Ophthalmoscope Operating Instruction Manual Retinoscope Transilluminator...
- Page 2 Thank you for purchasing the Welch Allyn Halogen PocketScope Set. The operating and maintenance instructions found in this manual are for both the Ophthalmic and Diagnostic model sets. They should be followed to ensure many years of accurate and reliable service.
- Page 3 Mode d'emploi des PocketScopes ™ Merci d'avoir acheté un jeu de PocketScope™ WelchAllyn. A la différence des poignées et des têtes, qui sont interchangeables, les lampes à utiliser sont spécifiques à chaque tête d'instrument. Veuillez consulter les diagrammes pour savoir comment remplacer les différentes lampes.
- Page 4 Bedienungsanleitung für PocketScopes ™ Wir bedanken uns für Ihren Kauf eines PocketScope™- Satzes von WelchAllyn. Obwohl die Griffe und Instrumentenköpfe untereinander austauschbar sind, werden für die verschiedenen Instrumentenköpfe verschiedene Lampen benötigt. Der Lampenaustausch ist auf den diagrammatischen Abbildungen angezeigt. Otoskop: (p. 7) 21131 –...
- Page 5 struzioni d'uso del PocketScopes ™ Grazie per avere acquistato un set PocketScope™ WelchAllyn. Le impugnature e le teste degli strumenti sono intercambiabili, tuttavia le teste degli strumenti richiedono l'uso di lampadine diverse. Per la sostituzione delle lampadine fare riferimento alle figure riportate qui di seguito.
- Page 6 Instrucciones de funcionamiento de PocketScopes ™ Le agradecemos su compra del SET PocketScope™ de WelchAllyn. Aunque los mangos y las cabezas del instrumento son intercambiables, se necesitan bombillas diferentes para las DISTINTAS cabezas del instrumento. En los diagramas se indica cómo cambiar de bombilla. Otoscopio: (p.
-
Page 7: Table Of Contents
PocketScope Retinoscope Retinoscope Features........6 PocketScope Otoscope Throat Illuminator..........7 PocketScope Ophthalmoscope Ophthalmoscope..........8 Ophthalmoscope Lens Instructions ....8-9 PocketScope Transilluminator Transilluminator Features ......10 Transilluminator Attachment ......10 Lamp Replacement Retinoscope Lamp Replacement....10-11 Otoscope Lamp Replacement .......11 Ophthalmoscope Lamp Replacement ..11-12 Transilluminator Lamp Replacement .....12 PocketScope Handles AA Battery Handle .........13 Convertible Handle (AA &... -
Page 8: Pocketscope Retinoscope Retinoscope Features
PocketScope Retinoscope Retinoscope Features • External focusing sleeve allows for easy adjustment regardless of what size hand or how instrument is held. Continuous 360Þ rotation. • Dust-free optics to keep instrument clean longer. • Fixation cards that easily attach for use during dynamic retinoscopy. -
Page 9: Pocketscope Otoscope Throat Illuminator
PocketScope Otoscope Throat Illuminator (21111 only) To convert otoscope to throat illuminator, unscrew otoscope head in counterclockwise direction. NOTE: Illuminator section can become hot. Avoid more than momentary direct skin contact. To turn instruments on and off, and vary intensity rotate switch at base of instrument head. -
Page 10: Pocketscope Ophthalmoscope Ophthalmoscope
PocketScope Ophthalmoscope 1. Rubber Brow Rest. 2. Aperture selection dial with continuous rotation: Allows access to microspot, small, large, fixation, slit and cobalt blue. 3. Lens Selection Dial — When used with multiplier lever, allows single diopter steps through 48 lens combinations (from +22 to –25 diopters). - Page 11 To move through the range on the negative (–) side: Rotate lens selection dial in negative (counter- clockwise) direction. At –9 diopters move lens dial counterclockwise again. Then move multiplier lever to “–” position. Continue moving lens dial in same counterclockwise direction to access –10 to –25 diopters.
-
Page 12: Pocketscope Transilluminator Transilluminator Features
PocketScope Transilluminator Transilluminator Features • Fiber Optic transmission for bright cool light transmission. • Curved design to fit into tight areas. Transilluminator Attachment Remove the retinoscope by turning the instrument in a counterclockwise direction. This will disconnect the retinoscope. Connect the transilluminator by turning the instrument in a clockwise direction. -
Page 13: Otoscope Lamp Replacement
3. Insert replacement lamp by carefully aligning pin on lamp shaft with slot in retinoscope. Push lamp in until firmly seated. Otoscope Lamp Replacement (21111 only) 1. Remove (unscrew) otoscope head. 2. Unscrew lamp holder in counterclockwise direction and remove from handle. 3. -
Page 14: Transilluminator Lamp Replacement
3. Insert replacement lamp by carefully aligning pin on lamp shaft with slot in ophthalmoscope head. Push lamp in until firmly seated. NOTE: If lamp surface is touched or becomes smudged, wipe clean with a soft cloth. This will assure longer lamp life and higher output. Align pin to slot in ophthalmoscope head... -
Page 15: Pocketscope Handles
Use alkaline batteries for best performance. 2. The AA handle can be upgraded to a convertible handle, which allows the handle to be used with AA batteries, Welch Allyn rechargeable batteries and the Universal Charger or PocketScope Desk Charger (obsolete). -
Page 16: Convertible Handle (Aa & Rechargeable)
Convertible PocketScope Handles (72800) For use with AA and Welch Allyn rechargeable batteries This handle can be used with either AA batteries or with Welch Allyn’s PocketScope rechargeable battery (#72600) and Desk Charger. NOTE: Only use the Welch Allyn Universal... -
Page 17: Batteries
NOTE: AA batteries will not charge and will not cause indicator lights to illuminate. NOTE: Only Welch Allyn rechargeable battery (#72600) is approved for use with these handles. #72600 Nickel Cadmium Rechargeable Battery Changing Batteries 1. -
Page 18: Cleaning Recommendations
– – “AA” Cells Recycling Batteries Welch Allyn now employs the services of an agency which can disassemble and recycle all components of nickel-cadmium batteries so that nothing gets land-filled or incinerated. Should you wish to dispose of your expended Welch Allyn rechargeable battery via recycling (in the U.S. -
Page 19: Replacement Parts
chemicals. Lens may be cleaned with warm water and soap. Handle – The PocketScope handle wipes clean with a damp cloth. Desk/Wall Charger – DO NOT pour water or any cleaning solution into charging wells. DO NOT autoclave Desk/Wall Charger, instruments or handles.
