For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE 2 Models
45018-01 • 01/29/08
Advertisement
Table of Contents
Related Manuals for Hunter 45018
Summary of Contents for Hunter 45018
- Page 1 Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. installation and operation manual for Hunter Ceiling Fans TYPE 2 Models 45018-01 • 01/29/08...
- Page 2 90% Pre-Assembled Out Of The Box! Makes Installation Fast in 3 Easy Steps 1. Install mounting bracket and make wiring connections 2. Attach EasyLock Blades 3. Install bulb(s) and glass Installation is complete! Please follow the detailed installation instructions inside this manual 45018-01 • 01/29/08 • Hunter Fan Company...
-
Page 3: Table Of Contents
8 • Operating and Cleaning Your Ceiling Fan ......13 9 • Troubleshooting....14 ©... - Page 4 Angled Mounting Style Angled Mounting recommended for a vaulted or angled ceiling 45018-01 • 01/29/08 • Hunter Fan Company Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods.
-
Page 5: Getting Ready
To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit... -
Page 6: Installing The Hanger Bracket
For proper alignment use slotted holes directly across from each other. If you are installing the fan on an ANGLED ceiling, be sure to orient the hanger bracket as shown in Illustration 2-3 (left or right view). -
Page 7: Assembling And Hanging The Fan
3-1 – 3-3. For low profile mounting (ceilings less than 8 feet high), go to steps 3-6 – 3-9 on the next page. 3-1. To assemble fan to hang down from a flat or angled ceiling, place the canopy and canopy trim ring around the adapter so that they rest on the fan assembly. - Page 8 3 • Assembling and Hanging the Fan (Low Profile Only) You can assemble your fan for standard or angled mounting as shown in steps 3-1 – 3-3 on the previous page. For low profile mounting (ceilings less than 8 feet high), see steps 3-6 – 3-10 on this page.
-
Page 9: Wiring The Fan
4-3. Connect the bare or green ground wire (grounded) from the ceiling to the green ground wire (grounded) from the ceiling plate and the green ground wire from the fan. 4-4. Connect the white wire (ungrounded) from the ceiling to the white wire (ungrounded) from the fan. -
Page 10: Installing The Canopy And Canopy
Should you need to remove the canopy trim ring, follow these steps: 1. Twist canopy trim ring counterclockwise until it releases from canopy. Step 5-5 Canopy Screw 45018-01 • 01/29/08 • Hunter Fan Company Steps 5-1 – 5-2 Hanger Bracket Canopy Trim Ring Canopy Step 5-3 Step 5-4... -
Page 11: Assembling The Blades
6-1. Open the locking mechanism. 6-2. Align the holes in the blade with the blade iron. 6-3. Close the locking mechanism securely. You will feel it lock into place. 6-4. Repeat steps 6-1 through 6-3 until all blades are installed. 45018-01 • 01/29/08 • Hunter Fan Company 6 • Assembling the Blades Open Step 6-1 Close Step 6-3... -
Page 12: Completing Your Installation With Or Without A Bowl Light Fixture
7-2. First install B10 candelabra bulbs (60 Watt Maximum) into the sockets. 7-3. Attach the extra pull chain (included) to the fan pull chain using the plastic breakaway connector. (You may find the plastic breakaway connector on the end of the extra chain.) 7-4. - Page 13 7-16. Install the switch housing cap and plug button to the lower switch housing. 7-17. Re-attach the lower switch housing back to the fan and reinstall the lower switch housing screws. 45018-01 • 01/29/08 • Hunter Fan Company Steps 7-12 – 7-16 Plug Button Lower Switch Housing Threaded Rod...
-
Page 14: Operating And Cleaning Your Ceiling Fan
8 • Operating and Cleaning Your Ceiling Fan 8-1. Turn on electrical power to the fan. 8-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. • Release slowly to prevent the chain from recoiling into the blades. • The chain uses a breakaway connector that separates if the chain is jerked. If this happens, simply reinsert the chain into the connector. -
Page 15: Troubleshooting
2. Check to see if the blade is cracked. If so, replace all the blades. Problem: Excessive wobbling. 1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade iron screws.
