WARNING : THIS OPTION IS NOT COMPATIBLE WITH THE VARIABLE HALOGEN
WARNING : IF THE SANDBOX OPTION IS PAIRED WITH A LOG KIT (AC04334,
AC04343), THE FOLLOWING INSTRUCTIONS ARE TO BE USED OVER THE ONE OF
SANDBOX
AC04371
INSTALLATION INSTRUCTIONS
LIGHTING KIT (AC04336)
THE LOG KIT.
46304A
2022-03-23
Advertisement
Related Manuals for Valcourt AC04371
Summary of Contents for Valcourt AC04371
- Page 1 SANDBOX ________________________________________________ AC04371 _________________________________________________ INSTALLATION INSTRUCTIONS _________________________________________________ WARNING : THIS OPTION IS NOT COMPATIBLE WITH THE VARIABLE HALOGEN LIGHTING KIT (AC04336) WARNING : IF THE SANDBOX OPTION IS PAIRED WITH A LOG KIT (AC04334, AC04343), THE FOLLOWING INSTRUCTIONS ARE TO BE USED OVER THE ONE OF THE LOG KIT.
