SANDBOX
________________________________________________
AC04371
_________________________________________________
INSTALLATION INSTRUCTIONS
_________________________________________________
WARNING : THIS OPTION IS NOT COMPATIBLE WITH THE VARIABLE HALOGEN
LIGHTING KIT (AC04336)
WARNING : IF THE SANDBOX OPTION IS PAIRED WITH A LOGS KIT (AC04334,
AC04343) , THESE INSTRUCTIONS ARE THE REFERENCE OVER THE LOGS KIT.
46304A
2022-03-16
Advertisement
Related Manuals for Valcourt AC04371
Summary of Contents for Valcourt AC04371
- Page 1 SANDBOX ________________________________________________ AC04371 _________________________________________________ INSTALLATION INSTRUCTIONS _________________________________________________ WARNING : THIS OPTION IS NOT COMPATIBLE WITH THE VARIABLE HALOGEN LIGHTING KIT (AC04336) WARNING : IF THE SANDBOX OPTION IS PAIRED WITH A LOGS KIT (AC04334, AC04343) , THESE INSTRUCTIONS ARE THE REFERENCE OVER THE LOGS KIT.
- Page 2 Remove the Invisimesh barrier and the glass door assemblies as per details A, B and C prior to installation sandbox. Remove decorative media and log set and log position pins (screw and spacers) from hearth and burner cover, if applicable. Page 2 Sandbox installation instruction – AC04371...
- Page 3 WARNING: Do not screw the screws all the way. Keep a space of 1/8 in (3 mm) between the head of the screw and the forming. 1/8’’ Pour the sand and spread it evenly in the sandbox. Page 3 Sandbox installation instruction – AC04371...
- Page 4 Insert the four tabs located at each corner of the sandbox opening into the burner opening to precisely position the sandbox on the burner cover. See DETAIL B: Make sure that every tab are in the burner opening. See DETAIL C: Page 4 Sandbox installation instruction – AC04371...
- Page 5 Follow the logs kit installation instruction, except for the following instructions: WARNING : Do not put in place the « J » rock on support « 3 ». Discard “J” rock. Put directly « B » rock on the support « 3 ». Sandbox installation instruction – AC04371 Page 5...
- Page 6 G3A 2H3 for problems, injuries,or damages arising out of the use of 418-908-8002 information contained in any document obtained from www.sbi-international.com unauthorized sources. Sandbox installation instruction – AC04371 Page 6...
