Argos Merrick 227/3031 Assembly Instructions Manual

Entertainment unit

Hide thumbs

page of 16

/ 16
Bookmarks

Quick Links

Download this manual

Merrick

Assembly Instructions

Dimensions

Width - 115cm

Depth - 45cm

Height - 58,3cm

Important

– Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline:

14-3B-246_01

Entertainment unit

- Please keep for future reference

227/3031

192/8105

0845 077 8888

Issue 2 - 14/04/15

Need help?

Do you have a question about the Merrick 227/3031 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Merrick 227/3031

Page 1 Entertainment unit Merrick Assembly Instructions - Please keep for future reference 227/3031 192/8105 Dimensions Width - 115cm Depth - 45cm Height - 58,3cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 077 8888 14-3B-246_01 Issue 2 - 14/04/15...
Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • To reduce the components and tools listed on the product, this could cause likelihood of the following pages.
Page 3 If you have damaged or missing commponents, Components - Panels call the Customer Helpline: 0845 077 8888 Please check you have all the panels listed below Left side panel x 1 Right side panel x 1 (45 x 39,2cm) (45 x 39,2cm) Top panel x 1 (45 x 115cm) Back panel x 1 (82,2 x 41,3cm)
Page 4 Components - Fittings Please check you have all the fittings listed below Note : The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 6/30mm Wooden dowel x 4 8/30mm Wooden dowel x 24 Spanner 13mm x 1 Nail x 38...
Page 5 Assembly Instructions Step 1 Attaching legs Position the leg shown on the picture, place the washer U and fix the nut T using the spanner. Repeat assembly for the remaining legs. Step 2 Preparation for the attaching of side panels and vertical dividing panels Insert screws E into the drilled holes of the base...
Page 6 Assembly Instructions Step 3 Preparation for the attaching of shelf Insert screws into the drilled holes of the left and right side panels , and fix them. Step 4 Preparation for the attaching of vertical dividing panel Insert screws E into the drilled holes of the shelf 14 and fix them.
Page 7 Assembly Instructions Step 5 Attaching the shelf Insert wooden dowels B into the shelf 14 and place the shelf 14 between the side panels 1 and 2 . Insert large locking nuts G into the drilled holes in shelf 14 and turn them clockwise to lock.
Page 8 Assembly Instructions Step 6 Attaching the vertical dividing panels Insert wooden dowels B into the vertical dividing panels 18 and place the vertical dividing panels 18 onto the shelf 14 . Insert cam bolts E 1 into the drilled holes in the shelf 14 .
Page 9 Assembly Instructions Step 7 Attaching the vertical dividing panels Insert wooden dowels B into the vertical dividing panel 24 and place the vertical dividing panel 24 onto the shelf 14 . Insert large locking nuts G into the drilled holes in vertical dividing panel 24 and turn them clockwise to lock.
Page 10 Assembly Instructions Step 8 Attaching base and top panel Insert wooden dowels B into the side panels 1 and 2 and vertical dividing panels 18 and 24 from the bottom and from the top and place the side panels 1 and 2 and vertical dividing panel 18 onto the base 4 and the top panel 3...
Page 11 Assembly Instructions Step 9 Note: You must ensure Attaching back panel the chest is square before attaching Position back panel 5, the back panel. 20 in position on the back of bedside chest. Position nails D 5 mm in from side edge of the back panel 5 , 20 with istance...
Page 12 Assembly Instructions Step 11 Stick the self-adhesive caps V onto the holes as shown on the picture.
Page 13 Assembly Instructions Step 12 Drawer assembly a: Insert screws into drawer front b: Insert wooden dowels into left and right drawer sides c: Insert plastic dowels into left drawer side and drawer back and fix it together using the hammer. d: Insert plastic dowels into right drawer side...
Page 14 Assembly Instructions Step 12 - continued g: Align correctly and insert small locking nuts into left and right drawer sides turn them clockwise to lock. h: Position left and right runners B to left and right drawer sides , fix using screws i: All drawers: Attach knobs...
Page 15 Assembly Instructions Step 13 Note: Wall fixings are not Fixing to wall supplied with this unit. It is recomended that the The correct type of fixing must chest is fixed to a wall. be used for your wall, seek professional advice if in doubt. Poke wall strap through the hole in the back panel and fix it to top...
Page 16 A Guide to Wall Mounting & Fixings IMPORTANT: When drilling into walls always check that there are no hidden wires or pipes etc. Make sure that the screws and wall plugs being used are suitable for supporting your unit. Consult a qualified tradesperson if you are unsure. HINTS: 1) General Rule Always use a larger screw and wall plug if you are not sure.

This manual is also suitable for:

Merrick 192/8105
