Attention
Install the control box in a horizontal position.
Do not change the position of the aerial.
The maximum authorised length of the cables connecting the control
box to the motors is 20 m.
The control box must be installed at least 40 cm above the ground.
The fastening bolts must be suitable for the type of mounting bracket.
M1 is the motor installed on the gate leaf which opens first and closes
last.
Warning
The 230V power supply cable must be secured using the cable
clamps supplied.
- The fuse only protects the 230 V area lighting.
The earth wire must always be longer than the live and neutral wires
in case of detachment.
If class 1 area lighting is to be connected, earth the control box (ter-
minal 3 or 4).
Warning
During this operation, secure the area and prevent anyone from
entering it.
-
-
