Summary of Contents for V-ZUG UnimaticDry V2000
- Page 1 Operating instructions UnimaticDry V2000 Tumble dryer...
- Page 2 Validity These operating instructions apply to: Model designation Model number Type UnimaticDry V2000 12007 UT2T-12007 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2022...
-
Page 3: Table Of Contents
Contents Changing the level of dryness ...... 20 Safety warnings 4 Automatic door opener........ 20 Symbols used............ 4 Restoring factory settings ........ 21 General safety precautions........ 4 Demo mode 21 Appliance-specific safety precautions .... 4 Instructions for use.......... 6 Switching on ............ -
Page 4: Safety Warnings
Safety warnings Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... - Page 5 1 Safety warnings ▪ WARNING: This appliance is ▪ Items such as foam rubber only designed for drying tex- (latex foam), shower caps, tiles which have been washed waterproof textiles, rubber or in water. plastic backed articles and ▪ The appliance is only to be clothes or pillows fitted with used with the recommended foam rubber pads should not...
-
Page 6: Instructions For Use
«Service & Sup- CoinSystem 1 or CoinSystem port» section. Please contact our Cus- tomer Services if necessary. 2 cashier system from V-ZUG ▪ Any repairs, modifications or manipula- Ltd into which you have inser- tions to the appliance, especially any... - Page 7 1 Safety warnings Caution: Risk of burns! Transport and installation ▪ Do not dry fabrics that contain traces of Front hair spray, hair gel, nail varnish remover or other similar substances. Danger of gas build-up! Caution: Risk to life! ▪ Packaging material, e.g. plastic film and polystyrene, can be dangerous for chil- dren and animals.
-
Page 8: Using For The First Time
Using for the first time Note If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again. Failure to do this can result in damage to the appliance. The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. -
Page 9: Where Is The Identification Plate
3 Appliance description Where is the identification plate? 1 Identification plate with serial number (SN) Note down the serial number (SN) of your appliance on the back page of these operat- ing instructions. Appliance description Appliance overview The appliance operates with a closed air circuit. Moisture is extracted from the air with the help of a heat pump and then the air is reheated. -
Page 10: Appliance Construction
3 Appliance description Appliance construction The appliance door can be set to open to the left or to the right. Our Customer Services can make the necessary adjustments to the appliance. 1 Appliance door 6 Temperature sensor 2 Door filter with door filter mat 7 Evaporator 3 Operating and display elements 8 Front filter with front filter mat... -
Page 11: Additional Programme
3 Appliance description Additional programme Timed drying Additional functions Without function End of programme Easy care ▪ Door opener ▪ Drum illumination Delayed start Digital display Various information appears in the digital display ( ) during the programme selec- tion and the programme sequence: ▪... -
Page 12: Programme Overview
4 Programme overview Programme overview About the consumption values The stated values for the programme duration and energy apply for the maximum stated capacity with a wash spun at around 1200 rpm (corresponds to a residual moisture of around 60%). A higher spinning speed or a smaller load reduce them by around 20–30 Automatic programmes To select the right programme, follow the fabric care symbols on the labels of the wash items, e.g. - Page 13 4 Programme overview Standard programme The most efficient programme for dry- ▪ Load: 1–7 kg ing normal wet cotton laundry. ▪ Remaining moisture content: -1 to 2 % ▪ Programme duration: 1h35 ▪ Energy: 1.66 kWh Crease guard Creases that come from spinning are ▪...
-
Page 14: Drying
5 Drying Drying Preparing the appliance After the appliance is transported or re-sited, it must be left to stand in the normal operating position for around 2 hours. Failure to do this can result in damage to the appliance. ▸ Insert plug into mains socket or turn on at wall switch. Loading the appliance ▸... -
Page 15: Selecting An Automatic Programme
5 Drying Changing programme selection During programme selection, a programme that has already been selected can be changed at any time by selecting a new programme. All previously selected settings are cleared. Aborting programme selection ▸ Touch the button. – Programme selection is aborted. Duration remaining indicator During programme selection, the expected duration of a programme is shown. -
Page 16: Selecting Timed Drying
5 Drying – The indicator light for the additional function that may be selected flashes for 15 seconds. A new programme can be selected during this time. All additional functions selec- ted are cleared and must be reselected. – If no button is touched within 15 seconds, the programme selected starts automat- ically. -
Page 17: Drum Illumination
5 Drying Shortening/Clearing the delayed start duration During the countdown to the delayed start, press the button repeatedly to shorten (in hourly steps) or clear the duration. Drum illumination The drum illumination automatically switches on whenever the appliance door is opened and switches off when it is closed. -
Page 18: End Of Programme
5 Drying The appliance can now be operated without regard to the childproof lock until the programme starts. Interrupting a programme through opening the appliance door ▸ To open the appliance door, hold the button depressed and at the same time touch the button. -
Page 19: User Settings
6 User settings User settings User settings can only be changed when no programme is running. The procedure is generally the same for all settings. Changing user settings ▸ Hold the button depressed for 5 seconds. – In the display appears: ▸... -
Page 20: Childproof Lock
6 User settings Childproof lock The childproof lock prevents a programme from being started accidentally. When the childproof lock is activated, a programme can only be started by pressing two buttons simultaneously. ▸ Hold the button depressed for 5 seconds. – In the display appears: ▸... -
Page 21: Restoring Factory Settings
7 Demo mode Switching the automatic door opener on/off ▸ Hold the button depressed for 5 seconds. – appears in the digital display. ▸ Touch the button repeatedly until the current setting appears in the digital display, e.g.: for automatic door opener OFF. ▸... -
Page 22: Care And Maintenance
8 Care and maintenance Care and maintenance Cleaning intervals Appliance Cleaning interval Cleaning part 1 Door filter Each time after tumble ▸ Remove any fluff. drying Whenever there is a ▸ Use an abrasive liquid cleaning agent heavier build-up of de- and a sponge, rinse with water and allow posits to drip dry;... -
Page 23: With Message "A9" Or "A11
8 Care and maintenance With message «A9» or «A11» A thick coating of fluff results in a reduced process air flow which can impair the drying process and trigger the «A9» or «A11» message. Check and, if necessary, clean the following parts in the appliance: ▪... -
Page 24: Cleaning The Door Filter / Door Filter Mat
8 Care and maintenance Cleaning the door filter / door filter mat Cleaning interval: Before change of user or with message «A9» / «A11» Do not operate the appliance without the door filter mat! Removing the door filter ▸ Open the filter cover 1. ▸... - Page 25 8 Care and maintenance For heavier deposits: ▸ Rinse the door filter 2 under running wa- ter. ▸ Clean with an abrasive liquid cleaning agent (immerse if necessary) and a sponge; use cleaning vinegar with hard water. ▸ Rinse off under running water and allow to drip dry.
-
Page 26: Cleaning The Front Filter / Front Filter Mat
8 Care and maintenance Cleaning the front filter / front filter mat Cleaning interval: Before change of user or with message «A9» / «A11» Do not operate the appliance without the door filter mat! The appliance will not start without the front filter being in place. Removing the front filter ▸... -
Page 27: Cleaning The Temperature Sensor
8 Care and maintenance Inserting the front filter / front filter mat The appliance will not start without the front filter being in place. ▸ Centre the front filter mat 3 in the front fil- ter 1 so that the edges of the front filter mat are flush with the front filter. -
Page 28: Cleaning The Cooler Filter
8 Care and maintenance ▸ Take out the front filter 1. ▸ Clean the evaporator 2, behind the grille, carefully using a vacuum cleaner with brush attachment. Cleaning the cooler filter Cleaning interval: As required or with message «A9» / «A11» Removing the cooler filter ▸... -
Page 29: Cleaning The Drum Illumination
9 Trouble-shooting ▸ Wash on a 40 °C wash programme to clean off heavier deposits. Inserting the cooler filter The cooler filter does not have to be dry before being inserted in the filter case. ▸ Put the cooler filter 2 into the filter case 1. - Page 30 9 Trouble-shooting Display Possible cause Solution ▪ The following parts in ▸ Check and, if necessary, clean the flashes or the appliance could parts. illuminates be blocked: ▸ Acknowledge the message by touch- – Door filter ing the button. – Door filter mat in ▸...
- Page 31 9 Trouble-shooting Display Possible cause Solution ▪ Pressing a pro- ▸ Hold the button depressed and at illuminates gramme selection the same time touch the required button several times programme selection button. while the childproof – The childproof lock has been lock is activated.
-
Page 32: Other Possible Problems
9 Trouble-shooting Other possible problems Problem Possible cause Solution It is not possible to ▪ A programme was in- ▸ Touch the button. select a new pro- terrupted. ▸ Select a new programme. gramme after closing the appliance door. The appliance will ▪... -
Page 33: Drying Tips
10 Drying tips Problem Possible cause Solution The programme ▪ The following parts in ▸ Check and, if necessary, clean the takes significantly the appliance could parts (see page 22). longer than indic- be blocked: ated. – Door filter – Door filter mat in door filter –... -
Page 34: Energy-Saving Tips
11 Spare parts ▪ Items of clothing with metal fasteners (e.g. overalls) should be tumble dried using timed drying. The metal fasteners could cause the washing to be overdried in an automatic programme. 10.3 Energy-saving tips ▪ Well-spun washing requires a shorter drying time, saving energy. –... -
Page 35: Technical Data
12 Technical data Cooler filter Technical data External dimensions Height: 90 cm Width: 66 cm Depth: 81 cm Weight: 94 kg Pumping height of pump: 1.2 m Load capacity: 7 kg dry washing Ambient conditions Permissible room temperature when appliance in operation: 5 °C to 35 °C Electrical connection ▸... -
Page 36: Light Sources
This product contains a light source of energy efficiency class E. 12.2 Product fiche In accordance with EU Regulation No. 392/2012 Brand V-ZUG Ltd The model identifier corresponds to the first alpha- 12007 numerics on the identification plate. Rated capacity for cotton laundry at full load... -
Page 37: Note For Testing Institutes
13 Disposal In accordance with EU Regulation No. 392/2012 Condensation efficiency class Condensation efficiency of the standard cotton pro- gramme at full load Condensation efficiency of the standard cotton pro- gramme at partial load Weighted condensation efficiency Sound power level 12.3 Note for testing institutes ▸... - Page 38 13 Disposal 13.3 Disposal The «crossed‐out wheeled bin» symbol requires the separate collection of waste ▪ electrical and electronic equipment (WEEE). Such equipment can contain hazardous, environmentally harmful materials. ▪ These appliances are to be handed over to a designated collection point for the recyc- ling of electrical and electronic equipment and must not be disposed of with unsorted household waste.
-
Page 39: Index
Index E42 ..............31 Easy care............13 A 0 ..............29 Electrical connection ........35 A 3 ..............29 End of the wash day ........18 A 9 ..............23 Energy-saving tips..........34 Cleaning the cooler filter ...... 28 Evaporator............10 Cleaning the door filter ....... 24 Cleaning ............ - Page 40 H 2.............. 30 Changing............ 19 H 4.............. 31 Exiting ............ 19 U 1 and E42 .......... 31 Overview............ 19 Model designation ..........2 Validity..............2 Note for testing institutes........ 37 Notes ..............41 Washing Loading............ 14 Preparing the appliance ......... 14 Unloading ............ 18 Problems ............
-
Page 41: Notes
Notes... -
Page 43: Service & Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements. - Page 44 At the end of the wash day: ▸ Clean the door filter ▸ Close the appliance door 1057879-03 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
