Operating instructions

UnimaticDry V4000

Tumble dryer

Table of Contents

Need help?

Do you have a question about the UnimaticDry V4000 and is the answer not in the manual?

Questions and answers

Summary of Contents for V-ZUG UnimaticDry V4000

Page 1 Operating instructions UnimaticDry V4000 Tumble dryer...
Page 2 Validity These operating instructions apply to: Model designation Model number Type UnimaticDry V4000 12038 UT4T-12038 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2025...
Page 3: Table Of Contents
Contents Brightness ............ 21 Safety warnings 4 Restoring factory settings........ 22 Symbols used ............ 4 Demo mode 22 General safety precautions ........ 4 Appliance-specific safety precautions.... 4 Switching on............ 22 Instructions for use .......... 6 Switching off............ 22 Using for the first time 8 Care and maintenance 23 Note ................ 8...
Page 4: Safety Warnings
Safety warnings Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...
Page 5 1 Safety warnings ▪ WARNING: This appliance is ▪ Items such as foam rubber only designed for drying tex- (latex foam), shower caps, tiles which have been washed waterproof textiles, rubber or in water. plastic backed articles and ▪ The appliance is only to be clothes or pillows fitted with used with the recommended foam rubber pads should not...
Page 6: Instructions For Use
3) is switched by a instructions given in the «Service & Sup- CoinSystem 1 or CoinSystem port» section. Please contact our Cus- 2 cashier system from V-ZUG tomer Services if necessary. ▪ Any repairs, modifications or manipula- Ltd into which you have inser-...
Page 7 1 Safety warnings Caution: Risk of burns! Transport and installation ▪ Do not dry fabrics that contain traces of Front hair spray, hair gel, nail varnish remover or other similar substances. Danger of gas build-up! Caution: Risk to life! ▪ Packaging material, e.g. plastic film and polystyrene, can be dangerous for chil- dren and animals.
Page 8: Using For The First Time
Using for the first time Note If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again. Failure to do this can result in damage to the appliance. The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions.
Page 9 2 Using for the first time ▸ To resume the function test, close the appliance door. Pause function test – In the plain text display appears: abort next – The indicator lights for the but- tons flash. ▸ Press the button.
Page 10: Appliance Description
3 Appliance description ▸ Press the button. – The following appears in the plain text display Function test complete for about 20 seconds: – The plain text display goes out. – The function test is finished. The function test can not be restarted after being aborted. Appliance description Appliance construction The appliance door can be set to open to the left or to the right.
Page 11: Operating And Display Elements
3 Appliance description Operating and display elements Operating panel Operating panel Plain text display Indicator light V-ZUG-Home display Automatic/Additional programme buttons Additional function buttons Extra dry Language selection Cupboard dry Delayed start Iron dry Ultra care Damp Easy care Woollens...
Page 12: Programme Overview
4 Programme overview Indicator light The buttons for the main programmes, the additional programme and certain additional functions are equipped with an indicator light. Activity State Indicator light is illuminated. Function is active. Indicator light is flashing. Function is selectable. Indicator light remains dark.
Page 13: Textile Programmes
4 Programme overview Textile programmes Programme Description Load Airing For refreshing or airing little-worn garments. 1–1.5 kg Silks For drying silk fabrics. Follow the fabric care 1–1.5 kg symbol as silk tends to crease easily. Low tem- perature for gentle drying. Fluffing Brings the bounce back to woollen textiles.
Page 14: Additional Functions
5 Drying Additional functions Programme Description Load Easy care Gentle drying for mixed fabrics (e.g. shirts, 1–2.5 kg pullovers and T-shirts). The level of dryness is reduced. Delayed start Take advantage of cheap-rate electricity (setting range of up to 24 hours). During shut-off periods –...
Page 15: General Note On Programme Selection
5 Drying When closing the appliance door, check that no items of washing are trapped. – In the display appears: Select programme – The indicator lights for the programme buttons flash. If no programme selection is made within 20 seconds, all the displays go out. However, it is still possible to make a programme selection.
Page 16: Selecting An Automatic Programme
5 Drying Drying phases The programme sequence for the automatic programmes has three drying phases: ▪ Drying: The washing is tumble dried until it reaches the set level of dryness. The dry- ing programme is monitored by a moisture sensor. As soon as the required level of dryness is reached, the «Cool down / Airing»...
Page 17: Selecting Ultra Care Or Easy Care
5 Drying Selecting ultra care or easy care ▸ While the indicator lights flash, touch the button. Selecting a delayed start ▸ Immediately after programme selection, hold the button depressed or press re- peatedly until the required delayed start duration (max. 24 hours) appears in the dis- play.
Page 18: Interrupting A Programme
5 Drying Interrupting a programme A running programme can be interrupted at any time to add or remove an item of wash- ing before time. After the appliance door is closed, the heat pump waits 5 minutes before starting again and the programme duration is correspondingly lengthened. ▸...
Page 19: End Of Programme
6 User settings 5.12 End of programme – In the plain text display appears: End of programme – The indicator light for the programme that Clean door ﬁlter has finished illuminates. «Crease guard» starts if the appliance is not unloaded. When it has finished, all the dis- plays go out.
Page 20: Possible User Settings
6 User settings Possible user settings The following diagram gives an overview of the possible user settings. ▸ Hold the button depressed for 5 seconds. User settings SN XXXXX XXXXXX ▪ OFF Childproof lock ▪ ON ▪ 1 very low final drying Level of dryness ▪...
Page 21: Level Of Dryness
6 User settings Level of dryness The appliance is designed to provide the most energy-efficient drying. The moisture sensor continually monitors the level of dryness of the washing. If the washing is not be- ing dried sufficiently – or being overdried – the level of dryness can be reset. Changing the level of dryness alters the level of dryness setting of all the pro- grammes.
Page 22: Restoring Factory Settings
7 Demo mode ▸ Touch the button repeatedly until the required Brightness setting appears in the display, e.g.: ▸ Touch the button repeatedly until the display goes out. Restoring factory settings The factory settings can be restored. ▸ Hold the button depressed for 5 seconds.
Page 23: Care And Maintenance
8 Care and maintenance Care and maintenance Cleaning intervals Appliance Cleaning interval Cleaning part 1 Door filter Each time after tumble ▸ Without using water, remove the fluff and drying dispose of in the waste bin. Whenever there is a ▸...
Page 24: With Message "A9" Or "A11
8 Care and maintenance Appliance Cleaning interval Cleaning part 6 Cooler filter As required with ▸ Without using water, remove any build- up of fluff and dispose of in the waste bin. Exterior of Occasionally ▸ Rub down with a damp cloth and wipe appliance dry.
Page 25: Removing Any Fluff
8 Care and maintenance Removing any fluff Cleaning interval: Each time after tumble drying The door filter does not have to be taken out for cleaning. ▸ Open the filter cover 1. ▸ Without using water, remove any fluff from the door filter 2. ▸...
Page 26 8 Care and maintenance Cleaning the door filter ▸ Hold the empty door filter 2 up to the light to detect deposits. ▸ Without using water, remove the fluff and deposits and dispose of in the waste bin. For any stubborn deposits that cannot be removed by dry wiping: ▸...
Page 27: Cleaning The Front Filter / Front Filter Mat
8 Care and maintenance Cleaning the front filter / front filter mat Cleaning interval: Before change of user or with message «A9» / «A11» The appliance will not start without the front filter being in place. Removing the front filter ▸...
Page 28: Cleaning The Temperature Sensor
8 Care and maintenance Inserting the front filter / front filter mat ▸ Centre the front filter mat 3 in the front fil- ter 1 so that the edges of the front filter mat are flush with the front filter. ▸ Put the inner part 2 on the front filter 1. ▸...
Page 29: Cleaning The Cooler Filter
8 Care and maintenance Cleaning the cooler filter Cleaning interval: As required or with message «A9» / «A11» Removing the cooler filter ▸ Take out the filter case 1. ▸ Push the handle back, open the filter case 1 and remove the cooler filter 2. Cleaning the cooler filter ▸...
Page 30: Trouble-Shooting
9 Trouble-shooting Trouble-shooting Error messages You may be able to trouble-shoot the following malfunctions yourself. If not, note down the error message in full (message, F and E numbers) and call Customer Services. Display Possible cause Solution ▪ The drain hose is ▸...
Page 31 9 Trouble-shooting Display Possible cause Solution ▪ Various situations can ▸ Acknowledge the message FXX / EXX see instructions SN XXXXX XXXXXX lead to this error mes- by touching the button. sage. ▸ Turn the power supply off for about 1 minute and then turn it back on again.
Page 32: Other Possible Problems
9 Trouble-shooting Display Possible cause Solution ▪ The laundry is being ▸ No action is necessary. The Final airing cooled down. laundry can be unloaded at any time as long as it is then spread out to cool down. ▪ A high ambient temper- ▸...
Page 33 9 Trouble-shooting Problem Possible cause Solution The washing is not dry ▪ Mixed laundry load. ▸ Select a longer programme. enough. ▸ Select timed drying. ▸ Change the level of dryness (see page 21). ▪ Interruption in power ▸ Insert plug into mains supply.
Page 34: Drying Tips
10 Drying tips Drying tips 10.1 Fabric care symbols To select the right drying programme, follow the fabric care symbols on garment labels. Tumble dry, medium heat Tumble dry, low heat Do not tumble dry 10.2 General tips ▪ Use tumble dryer sheets sparingly. ▪...
Page 35: Spare Parts
Front filter mat Cooler filter V-ZUG Ltd provides spare parts for 15 years after the making available on the market of the last appliance with this type designation. Deviations from this are subject to consider- ation of and compliance with the applicable ecodesign regulations on the availability of spare parts.
Page 36: Technical Data
12 Technical data Technical data External dimensions Height: 90 cm Width: 66 cm Depth: 81 cm Weight: 94 kg Pumping height of pump: 1.2 m Load capacity: 7 kg dry washing Ambient conditions Permissible room temperature when appliance in operation: 5 °C to 35 °C Electrical connection ▸...
Page 37: Consumption Values
12 Technical data 12.3 Consumption values The stated values for the programme duration and energy apply to the stated load capa- city with a wash spun at around 1000 rpm (corresponds to a moisture level of approx. 60%). A higher spin speed or a smaller load reduce them by approx. 20–30%. The val- ues given for programmes other than the «Cottons eco»...
Page 38: Product Fiche
13 Disposal 12.4 Product fiche Product information in accordance with EU Regulation 2023/2534 Appliance-specific data is stored in the European Product Registry for Energy Labelling (EPREL) database. To identify the appliance: ▸ scan the QR code on the energy label and follow the link or alternatively ▸...
Page 39: Index
Index Cleaning ............ 25 Drying............14, 16 A 0 ..............30 A 3 ..............30 A 9 ..............24 Easy care............14 Cleaning the cooler filter ...... 29 Electrical connection ........36 Cleaning the door filter ....... 25 End of the wash day ........19 Cleaning the door filter mat .......
Page 40 Tumble dry, low heat Baby garments.......... 13 Preparing the appliance ......... 14 Shirts .............. 13 Problems ............30 Tumble dryer sheets ........34 Appliance not starting......... 32 Type............... 2 Programme duration too long .... 33 Programme selection with door closed ................
Page 41: Notes
Notes...
Page 43: Service And Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
Page 44: Quick Instructions
▸ Close the appliance door At the end of the wash day: ▸ Clean the door filter ▸ Close the appliance door 1290444-02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
