  • Page 1 Operating instructions Unimatic TL WP Tumble dryer...
  • Page 2 The product family (model number) corresponds to the first alphanumerics on the identi- fication plate. These operating instructions apply to: Model Type Product family Unimatic TL WP WT-UTL-WP Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2018...

  • Page 3: Table Of Contents

    Contents End of programme ..........  20 Safety precautions  4 Care and maintenance  21 Symbols used............ 4 General safety precautions........ 4 Cleaning intervals ..........  21 Appliance-specific safety precautions .... 4 A9 error message..........  22 Instructions for use.......... 6 A11 error message ..........

  • Page 4: Safety Precautions

    Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...
  • Page 5 1 Safety precautions ▪ This appliance is only suitable or pillows fitted with foam rub- for drying textiles which have ber pads should not be dried been washed in water. in the tumble dryer. ▪ The appliance is only to be ▪...

  • Page 6: Instructions For Use

    1 Safety precautions ▪ Do not operate the appliance without a Instructions for use door filter or with a damaged door filter. Fluff can destroy the appliance! Before using for the first time Caution: Burns hazard! ▪ The appliance must be installed and connected to the electricity supply in ▪...

  • Page 7: Using For The First Time

    Using for the first time Note The appliance can only be operated after standing in the normal operating posi- tion for about 2 hours. The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work.

  • Page 8: Where Is The Identification Plate

    3 Appliance description Where is the identification plate? 1 Identification plate with serial number (FN) Note down the serial number (FN) of your appliance on the back page of these operat- ing instructions. Appliance description Appliance overview The appliance operates with a closed air circuit. Moisture is extracted from the air with the help of a heat pump and then the air is reheated.

  • Page 9: Appliance Construction

    3 Appliance description Appliance construction The appliance door can be set to open to the left or to the right. Our Customer Services can make the necessary adjustments to the appliance. 1 Identification plate / serial number (FN) 2 Operating and display elements 3 Door filter 4 Appliance door 5 Temperature sensor...

  • Page 10: Operating And Display Elements

    3 Appliance description Operating and display elements Automatic programmes Extra dry Damp Normal dry Woollens Iron dry Crease guard Additional programme Timed drying Additional functions Easy care End of programme Delayed start Door opener Display elements display (digital display) for: ▪...

  • Page 11: Programme Overview

    4 Programme overview Programme overview Programme sequence for the automatic programmes The drying programme has 3 phases: Drying The washing is tumble dried until it reaches the set level of dryness. The drying pro- gramme is monitored by a moisture sensor. As soon as the required level of dryness is reached, the «Cooling down/Airing»...

  • Page 12: Additional Programme

    4 Programme overview Woollens 1 kg For woollen fabrics labelled as washable. Gentle drying through a gentle drum action and a low temperature (approx. 45° C). Crease guard 1–3 kg Creases that come from spinning are reduced (e.g. shirts, blouses). The laun- dry is ready for ironing.

  • Page 13: User Settings

    5 User settings User settings User settings can only be changed when no programme is running. The procedure is generally the same for all settings. Changing user settings ▸ Hold the button depressed for 5 seconds. – In the display appears: ▸...

  • Page 14: Childproof Lock

    5 User settings Childproof lock The childproof lock prevents a programme from being started accidentally. When the childproof lock is activated, a programme can only be started by pressing two buttons simultaneously. ▸ Hold the button depressed for 5 seconds. –...

  • Page 15: Automatic Door Opener

    5 User settings Automatic door opener If the automatic door opener is switched on, the appliance door opens automatically at the end of the programme. Otherwise it remains closed and can be opened by pressing button. Switching the automatic door opener on/off ▸...

  • Page 16: Drying

    6 Drying Drying Preparing the appliance After the appliance is transported or re-sited, it must be left to stand in the normal operating position for around 2 hours. Failure to do this can result in damage to the appliance. ▸ Plug the appliance in at the mains or turn the wall switch on. Loading the appliance ▸...
  • Page 17 6 Drying Changing programme selection During programme selection, a programme that has already been selected can be changed at any time by selecting a new programme. All previously selected settings are cleared. Aborting programme selection ▸ Press the button. – Programme selection is aborted. Duration remaining indicator During programme selection, the expected duration of a programme is shown.

  • Page 18: Selecting A Delayed Start

    6 Drying Selecting timed drying ▸ Close the appliance door. – The indicator lights for the programme buttons and the additional programme flash. ▸ Press the button. ▸ Press repeatedly to select the desired duration, i.e. 10, 20, 30, 40, 50, 60 or 90 minutes.

  • Page 19: Interrupting A Programme

    6 Drying Interrupting a programme A running programme can be interrupted at any time to add or remove an item of wash- ing before time. After the appliance door is closed, the heat pump waits 10 minutes before starting again and the programme duration is correspondingly lengthened. ▸...

  • Page 20: End Of Programme

    6 Drying Aborting a programme through button selection With the appliance door closed, carry out the following step: ▸ Hold the active programme button – the indicator light illuminates – depressed and at the same time press the button. – The programme is aborted. End of programme –...

  • Page 21: Care And Maintenance

    7 Care and maintenance Care and maintenance Cleaning intervals Appliance part Cleaning interval Cleaning 1 Door filter Each time after Remove any fluff. tumble drying Whenever there is a Use an abrasive liquid cleaning agent and a heavier build-up of sponge, rinse with water and allow to drip dry;...

  • Page 22: A9 Error Message

    7 Care and maintenance * A coating of fluff can build up more or less quickly depending on the type of wash and the size of load. A9 error message A thick coating of fluff results in a reduced process air flow which can impair the drying process and trigger the «A9»...

  • Page 23: Cleaning The Door Filter / Filter Mat

    7 Care and maintenance ▸ Remove any fluff from the door filter and the base filter. ▸ Close the filter cover. Cleaning the door filter / filter mat Wash before change of user or «A9» Removing the filter mat Do not operate the appliance without the filter mat. Cleaning the door filter ▸...

  • Page 24: Cleaning The Base Filter

    7 Care and maintenance Cleaning the filter mat ▸ Remove the fluff while dry, then rinse un- der running water. Finally, squeeze out the water. ▸ Wash on a 40 °C wash programme to clean off heavier deposits. Inserting the door filter / filter mat Do not operate the appliance without the filter mat.

  • Page 25: Cleaning The Temperature Sensor

    7 Care and maintenance ▸ Hold the filter up to the light to detect de- posits. Wash the filter to clean off heavy deposits. ▸ Clean with an abrasive liquid cleaning agent (immerse if necessary) and a sponge; use cleaning vinegar with hard water.

  • Page 26: Cleaning The Cooler Filter

    7 Care and maintenance ▸ Clean the heat pump mat 3, behind the grille, carefully using a brush and va- cuum cleaner with the crevice tool at- tachment. 7.10 Cleaning the cooler filter As required or with «A11» ▸ Push the handle back, open the filter case and remove the cooler filter.

  • Page 27: Trouble-Shooting

    8 Trouble-shooting Trouble-shooting This section lists faults that can be solved simply by following the instructions given. If another fault is displayed or the fault cannot be remedied, please call Customer Ser- vices. Before calling Customer Services, please note down the error message in full. What to do if ...
  • Page 28 8 Trouble-shooting ... A11 appears in the display Possible cause Solution ▪ The following parts in the ap- ▸ Check and, if necessary, clean the parts. pliance could be blocked: ▸ Cancel the error message by pressing the but- – heat pump filter ton.
  • Page 29 8 Trouble-shooting ... in the display appears Possible cause Solution ▪ Pressing a programme button ▸ Hold the button depressed and at the same several times while the child- time press the required programme button. The proof lock is activated. childproof lock has been overridden.
  • Page 30 8 Trouble-shooting ... it is not possible to select a new programme after closing the appliance door Possible cause Solution ▪ A programme was interrupted. Press the button. Select a new programme..the appliance does not start Possible cause Solution ▪...

  • Page 31: Drying Tips

    9 Drying tips ... the programme takes significantly longer than indicated Possible cause Solution ▪ The following parts in the appli- ▸ Check and, if necessary, clean the parts. ance could be blocked: – door filter – filter mat in door filter –...

  • Page 32: Energy-Saving Tips

    10 Spare parts ▪ Items of clothing with metal fasteners (e.g. overalls) should be tumble dried using the additional timed drying programme. The metal fasteners could cause the washing to be overdried in an automatic programme. Energy-saving tips ▪ Well-spun washing requires a shorter drying time, saving energy. –...

  • Page 33: Technical Data

    11 Technical data Technical data Dimensions Height: 90 cm Width: 66 cm Depth: 81 cm Weight: 94 kg Pumping height of pump: 1.2 m Dry load capacity: 7 kg Ambient conditions Permissible room temperature when appliance in operation: 5 °C to 35 °C Electrical connection ▸...

  • Page 34: Product Fiche

    11 Technical data 11.1 Product fiche In accordance with EU Regulation No. 392/2012 Brand V-ZUG Ltd The model identifier corresponds to the first alpha- numerics on the identification plate. Rated capacity for cotton laundry at full load Type of appliance...

  • Page 35: Consumption Values

    11 Technical data 11.2 Consumption values The stated values for the programme duration and energy apply for the maximum stated capacity with a wash spun at around 1200 rpm (corresponds to a residual moisture of around 60%). A higher spinning speed or a smaller load reduce them by around 20–30 Automatic programmes Programme Load capa-...

  • Page 36: Disposal

    12 Disposal Disposal 12.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 12.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...

  • Page 37: Index

    Index Start .............. 7 Additional filter mat Cleaning ............ 25 Heat pump mat Ambient conditions.......... 33 Cleaning ............ 25 Appliance Preparing............ 16 Appliance description ........8 Instructions for use ..........6 Appliance disposal .......... 36 Automatic door opener........15 Automatic programmes ........11 Level of dryness ..........
  • Page 38 Technical data ..........33 Temperature sensor Cleaning ............ 25 Testing institutes: Note........35 Timed drying ............. 12 Selecting............ 18 Tips ..............31 Tumble dryer sheets........31 Type............... 2 User settings............. 13 Changing............ 13 Exiting ............ 13 Overview............ 13 Validity..............2 Washing Loading............

  • Page 39: Service & Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
  • Page 40 At the end of the wash day: ▸ Clean the door filter ▸ Close the appliance door 1030209-R02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
