Operating instructions

UnimaticDry V2000

Tumble dryer

Table of Contents

Need help?

Do you have a question about the UnimaticDry V2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for V-ZUG UnimaticDry V2000

Page 1 Operating instructions UnimaticDry V2000 Tumble dryer...
Page 2 Validity These operating instructions apply to: Model designation Model number Type UnimaticDry V2000 12037 UT2T-12037 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2025...
Page 3: Table Of Contents
Contents Switching on............ 20 Safety warnings 4 Switching off............ 20 Symbols used ............ 4 Care and maintenance 21 General safety precautions ........ 4 Appliance-specific safety precautions.... 4 Cleaning intervals.......... 21 Instructions for use .......... 6 With message «A9» or «A11» ...... 22 Build-up of fluff............. 22 Using for the first time 8 Removing any fluff ..........
Page 4: Safety Warnings
Safety warnings Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that...
Page 5 1 Safety warnings ▪ WARNING: This appliance is ▪ Items such as foam rubber only designed for drying tex- (latex foam), shower caps, tiles which have been washed waterproof textiles, rubber or in water. plastic backed articles and ▪ The appliance is only to be clothes or pillows fitted with used with the recommended foam rubber pads should not...
Page 6: Instructions For Use
3) is switched by a instructions given in the «Service & Sup- CoinSystem 1 or CoinSystem port» section. Please contact our Cus- 2 cashier system from V-ZUG tomer Services if necessary. ▪ Any repairs, modifications or manipula- Ltd into which you have inser-...
Page 7 1 Safety warnings Caution: Risk of burns! Transport and installation ▪ Do not dry fabrics that contain traces of Front hair spray, hair gel, nail varnish remover or other similar substances. Danger of gas build-up! Caution: Risk to life! ▪ Packaging material, e.g. plastic film and polystyrene, can be dangerous for chil- dren and animals.
Page 8: Using For The First Time
Using for the first time Note If the location of the appliance is changed, because of the heat pump it must stand in its final position for around 2 hours before it can be operated again. Failure to do this can result in damage to the appliance. The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions.
Page 9: Appliance Description
3 Appliance description ▸ Press the button. – appears in the digital display. – The indicator light for the button flashes. ▸ Press the button to resume the function test. – The function test is resumed. – The duration remaining, e.g. , appears again in the digital display.
Page 10: Operating And Display Elements
3 Appliance description Operating and display elements Operating panel Operating panel Level of dryness display Indicator light Without function Digital display Automatic/Additional programme buttons Additional function buttons Extra dry Delayed start Cupboard dry Easy care Iron dry End of programme Damp Door opener / Drum illumination Woollens...
Page 11: Programme Overview
4 Programme overview Indicator light The buttons for the main programmes, the additional programme and certain additional functions are equipped with an indicator light. Activity State Indicator light is illuminated. Function is active. Indicator light is flashing. Function is selectable. Indicator light remains dark.
Page 12: Additional Functions
5 Drying Additional functions Programme Description Load Easy care Gentle drying for mixed fabrics (e.g. shirts, 1–2.5 kg pullovers and T-shirts). The level of dryness is reduced. Delayed start Take advantage of cheap-rate electricity (setting range of up to 24 hours). During shut-off periods –...
Page 13: General Note On Programme Selection
5 Drying If no programme selection is made within 20 seconds, all the displays go out. However, it is still possible to make a programme selection. General note on programme selection Use the 'Programme overview' to determine which programme is the most suitable for your washing.
Page 14: Selecting An Automatic Programme
5 Drying ▪ Crease guard: The dried washing is moved at frequent intervals to prevent creasing. If the additional «Easy care» function has been selected, «Crease guard» runs 90 minutes; with all other programmes it runs 30 minutes. «Crease guard» can be stopped at any time by opening the appliance door or by touching the button.
Page 15: Selecting Easy Care
5 Drying Selecting easy care ▸ Press the button while the indicator light is flashing. Selecting a delayed start ▸ Immediately after programme selection, hold the button depressed or press re- peatedly until the required delayed start duration (max. 24 hours) appears in the dis- play.
Page 16: Interrupting A Programme
5 Drying Interrupting a programme A running programme can be interrupted at any time to add or remove an item of wash- ing before time. After the appliance door is closed, the heat pump waits 5 minutes before starting again and the programme duration is correspondingly lengthened. ▸...
Page 17: End Of Programme
6 User settings 5.12 End of programme – appears in the digital display. – The indicator light for the pro- gramme that has finished illu- minates. «Crease guard» starts if the appliance is not unloaded. When it has finished, all the dis- plays go out.
Page 18: Possible User Settings
6 User settings Exiting user settings ▸ Touch the button repeatedly until the digital display goes out. If no button is touched within the next 20 seconds, user settings is exited and the digital display goes out. Possible user settings The following diagram gives an overview of the possible user settings.
Page 19: Changing The Level Of Dryness
6 User settings Changing the level of dryness The appliance is designed to provide the most energy-efficient drying. The moisture sensor continually monitors the level of dryness of the washing. If the washing is not be- ing dried sufficiently – or being overdried – the level of dryness can be reset. Changing the level of dryness alters the level of dryness setting of all the pro- grammes.
Page 20: Demo Mode
7 Demo mode Demo mode In the demo mode, almost all the appliance functions are available but it is not possible to dry with the appliance. Switching on ▸ Open the appliance door (press at side edge of door) or touch the button.
Page 21: Care And Maintenance
8 Care and maintenance Care and maintenance Cleaning intervals Appliance part Cleaning interval Cleaning 1 Door filter Each time after ▸ Without using water, remove the fluff and tumble drying dispose of in the waste bin. Whenever there is a ▸...
Page 22: With Message "A9" Or "A11
8 Care and maintenance Appliance part Cleaning interval Cleaning 6 Cooler filter As required with ▸ Without using water, remove any build- up of fluff and dispose of in the waste bin. Exterior of ap- Occasionally ▸ Rub down with a damp cloth and wipe pliance dry.
Page 23: Removing Any Fluff
8 Care and maintenance Removing any fluff Cleaning interval: Each time after tumble drying The door filter does not have to be taken out for cleaning. ▸ Open the filter cover 1. ▸ Without using water, remove any fluff from the door filter 2. ▸...
Page 24 8 Care and maintenance Cleaning the door filter ▸ Hold the empty door filter 2 up to the light to detect deposits. ▸ Without using water, remove the fluff and deposits and dispose of in the waste bin. For any stubborn deposits that cannot be removed by dry wiping: ▸...
Page 25: Cleaning The Front Filter / Front Filter Mat
8 Care and maintenance Cleaning the front filter / front filter mat Cleaning interval: Before change of user or with message «A9» / «A11» The appliance will not start without the front filter being in place. Removing the front filter ▸...
Page 26: Cleaning The Temperature Sensor
8 Care and maintenance Inserting the front filter / front filter mat ▸ Centre the front filter mat 3 in the front fil- ter 1 so that the edges of the front filter mat are flush with the front filter. ▸ Put the inner part 2 on the front filter 1. ▸...
Page 27: Cleaning The Cooler Filter
8 Care and maintenance Cleaning the cooler filter Cleaning interval: As required or with message «A9» / «A11» Removing the cooler filter ▸ Take out the filter case 1. ▸ Push the handle back, open the filter case 1 and remove the cooler filter 2. Cleaning the cooler filter ▸...
Page 28: Trouble-Shooting
9 Trouble-shooting Trouble-shooting Error messages You may be able to trouble-shoot the following malfunctions yourself. If not, note down the error message in full (message, F and E numbers) and call Customer Services. Display Possible cause Solution ▪ The drain hose is ▸...
Page 29 9 Trouble-shooting Display Possible cause Solution ▪ The door filter is ▸ Insert the door filter and ensure it is illuminates missing. positioned correctly, or close the ap- ▪ The appliance door pliance door. is open. ▸ Acknowledge the message by touch- ing the button.
Page 30: Other Possible Problems
9 Trouble-shooting Display Possible cause Solution ▪ Various situations ▸ Acknowledge the message by touch- can lead to this error ing the button. flash alternately message. ▸ Turn the power supply off for about 1 minute and then turn it back on again.
Page 31 9 Trouble-shooting Problem Possible cause Solution The appliance will ▪ The appliance door ▸ Close the appliance door. not start. is open. ▪ Interruption in power ▸ Insert plug into mains socket. supply. ▸ Turn wall switch on. ▸ Check fuse or circuit breaker. The washing is not ▪...
Page 32: Drying Tips
10 Drying tips Problem Possible cause Solution The washing is ▪ Wash items that are ▸ Static charge is a normal character- charged with static made of man-made istic of man-made fibres and nothing electricity. fibres. to do with the appliance. Drying tips 10.1 Fabric care symbols...
Page 33: Spare Parts
Front filter mat Cooler filter V-ZUG Ltd provides spare parts for 15 years after the making available on the market of the last appliance with this type designation. Deviations from this are subject to consider- ation of and compliance with the applicable ecodesign regulations on the availability of spare parts.
Page 34: Technical Data
12 Technical data Technical data External dimensions Height: 90 cm Width: 66 cm Depth: 81 cm Weight: 94 kg Pumping height of pump: 1.2 m Load capacity: 7 kg dry washing Ambient conditions Permissible room temperature when appliance in operation: 5 °C to 35 °C Electrical connection ▸...
Page 35: Consumption Values
12 Technical data 12.3 Consumption values The stated values for the programme duration and energy apply to the stated load capa- city with a wash spun at around 1000 rpm (corresponds to a moisture level of approx. 60%). A higher spin speed or a smaller load reduce them by approx. 20–30%. The val- ues given for programmes other than the «Cottons eco»...
Page 36: Disposal
13 Disposal Disposal 13.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 13.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸...
Page 37: Index
Index Electrical connection ........34 End of the wash day ........17 A 0 ..............28 Energy-saving tips ........... 32 A 3 ..............28 Evaporator............9 A 9 ..............22 Cleaning ............ 26 Cleaning the cooler filter ...... 27 External dimensions ........34 Cleaning the door filter .......
Page 38 Model designation ..........2 Validity..............2 Preparing the appliance ......... 12 Problems ............28 Washing Appliance not starting......... 31 Loading............ 12 Programme duration too long .... 31 Removing ............ 17 Programme selection with door closed ................ 30 Washing charged with static electricity ... 32 Programme Aborting ............
Page 39: Service And Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements.
Page 40: Quick Instructions
▸ Close the appliance door At the end of the wash day: ▸ Clean the door filter ▸ Close the appliance door 1290419-02 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
