Commercial HydroTap
Filtered boiling and chilled drinking water for Commercial kitchens and tea rooms.
This Installation Instruction covers the following Commercial HydroTap models
Affix Model Number Label Here
86682
Hydro Tap Installation and Operating Instructions - 86682 - March 2012 v1.05
Installation and Operating Instructions
HydroTap
®
Page 1 of 20
Advertisement
Table of Contents
Related Manuals for Zip Commercial HydroTap 86682
Summary of Contents for Zip Commercial HydroTap 86682
- Page 1 Installation and Operating Instructions Commercial HydroTap ® Filtered boiling and chilled drinking water for Commercial kitchens and tea rooms. This Installation Instruction covers the following Commercial HydroTap models Affix Model Number Label Here 86682 HydroTap Hydro Tap Installation and Operating Instructions - 86682 - March 2012 v1.05 Page 1 of 20...
- Page 2 Installation Checklist Before Installation: Read the instructions Note: Not all fittings are supplied with the appliance kit. Isolation valves are not supplied Check the water pressure to determine if you require a pressure reduction valve or a flow restrictor added or removed from the kit. Check the water quality to determine if extra filtration will be required.
-
Page 3: Table Of Contents
NOTE: Read all instructions and precautions before proceeding. If in doubt, or need further guidance, please call Zip on 0800 077 8302. Please leave these instructions with the end user after installation This unit must be installed in accordance with water supply byelaws, current IEE regulations and relevant local authority byelaws. -
Page 4: Read These Warnings First
Lifting Take care when lifting the Zip HydroTap undersink unit. Some units may exceed safe lifting guidelines. If you feel this is beyond your personal capabilities, please seek assistance with the lift. The weights of the units are marked on the packaging and are given in the table on P6. - Page 5 Warning: Zip HydroTaps are designed to operate within 1ºC to 2ºC of set point for boiling water and at 5ºC to 15ºC BC120/60+ or 5°C to 10°C BC160125+ and BC200/175+ for chilled drinking water. All boiling water units are self calibrating to 98ºC, which is the recommended setting.
-
Page 6: Models Covered By These Instructions
Models Covered by These Instructions Note: The Cup measurement =167ml, the Glass measurement = 200ml These Installation Instructions cover the entire Commercial HydroTap range. Use the chart on the left to identify the model you are using: BC = Boiling and Chilled, Filtered, Cups of Glasses of Model... -
Page 7: Installation Procedure
(supplied) to the cold water inlet on the unit. This is located at the rear of the unit. Position the Zip HydroTap undersink unit as close as possible to directly beneath the Zip HydroTap tap head. The connection tubes supplied with the tap head assembly CANNOT be lengthened. -
Page 8: Step C - Connecting The Tap
(Not supplied as standard equipment). BC120/60+ To combat the build up of lime scale, a high performance external filter kit may be ordered from your Zip service provider. NOTE: - When fitted, the external filter will supply filtered water only for the Hot tank. - Page 9 - The rear of the unit is fitted with, 1/4” John Guest, inlet and outlet fittings, specifically for the Zip high performance filter kit. - These instructions must be read in conjunction with the filter fitting instructions supplied with the high performance filter kit.
-
Page 10: Step E - Connecting The Water Supply
Installation Procedure continued Step E - Connecting the water supply To prevent sediment from entering the Zip HydroTap at connection, flush NOTE : water through the supply line thoroughly before connection to the Zip New hose sets supplied with the HydroTap. -
Page 11: Step G - Temperature And Set Point Adjustment
0.5ºC increments between 68º - 100ºC. Note: the Maximum setting of 100ºC is not recommended for normal use. Do not raise temperature above 98.5ºC without consulting Zip first to discuss the service issue. -
Page 12: Font Installation Procedure
Font Installation Procedure Position the Font template (provided) on the bench area. Ensure the position you select is within the length of the supply tube and USB cable fixed to the Tap Head Assembly. These cannot be extended 2. Check again for correct positioning. The supply hoses must have constant fall back to the tank assembly. -
Page 13: Operating The Tap
This indicates that the chilled water is not at the right temperature. Wait up to 20 minutes. When the chilled water is at the right temperature, the light will stop flashing. Note: The Zip HydroTap is designed to dispense chilled water in the temperature range 5°C to 15°C for BC120/60+ or 5°C to 10°C for BC160/125+ and BC200/175+ depending on settings. -
Page 14: Child Safety Lock
Safety Lock Safety Lock (boiling / chilled models) The safety lock can be activated to prevent boiling water flowing if the hot lever is inadvertently activated. To activate, first press the safety lock then depress the Blue Chilled water lever for a period of approximately ten seconds. -
Page 15: Setting The Energy Saver Timer
Setting the Energy Saver Timer (products with this feature only) Normal Operation Set Time To change time, press either Menu or Menu button until Set Time is on the display screen. Press Adjust button to increase time or Adjust button to decrease time. -
Page 16: Auxiliary Fan Attachment
Auxiliary Fan Attachment The HydroTap is equipped with an auxiliary fan connection point on the rear panel close to the Auxiliary fan connection cold water inlet / flex and plug area. The fan kit is available as a spare part. The fan operates in parallel with the Condenser fan helping to remove heat from the cupboard space. -
Page 17: Internal Filter Replacementr
Internal Filter Replacement The Zip HydroTap notifies when filter replacement is due. The default setting is 6000 Ltrs, but this can be set in increments of 1000Ltr from 1000Ltr to 10000Ltrs. When a filter change is due, the Change Filter light will flash white once a minute and remain so until reset. -
Page 18: Trouble Shooting
16. Close the door to secure the appliance. Warning: If the Zip HydroTap is switched off for a long period of time (e.g. More than a weekend), run water through the chilled water outlet for at least 5 minutes before consumption. -
Page 19: Typical Undersink Layout
Typical undersink layout Fused Spur Hydro Tap Installation and Operating Instructions - 86682 - March 2012 v1.05 Page 19 of 20... -
Page 20: End Of Life Disposal
Zip Heaters (UK) Ltd warrants that, should any part fail within 12 calendar months of installation, that part will be repaired or replaced free of charge by Zip or its Distributor or Service Provider, except as set out below, provided the appliance is installed and used strictly in accordance with the instructions supplied, and that failure is not due to accident, misuse, abuse, unsuitable water conditions, or to any alteration, modification or repair by any party not expressly nominated by Zip.
