- Page 1 Installation and Operating Instructions Zip Heavy Duty Filter Tap Cold Water Filtration (unchilled) Affix Model Number Label Here 803828 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02 Page 1 of 8...
-
Page 2: Installation Instructions
Align the tabs of the cartridge with the filter housing and insert it into the socket. Turn the cartridge a quarter turn to the right until it stops and locks into position. Check that the direction of flow on the filter head is correct. Page 2 of 8 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02... - Page 3 Valve. It must end up connected so that they point in the direction of the Flow. (See Installation Diagram on Pg 4.) 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02 Page 3 of 8...
-
Page 4: Installation Diagram
Valve BLUE Tube WHITE Tube Outlet Inlet JG Elbow 92337 - Filter head JG 1/4” x 3/8” NPT fittings 90992 Filter Cartridge Page 4 of 8 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02... -
Page 5: Filling The System
The filter cartridge and tubing are full of air until purged, and the filter cartridge requires activation when first installed. Rotate and hold the operating lever on the Zip Filter Tap, allowing water to flow for a minimum of five minutes, until all of the air has been purged from the system, and the cartridge has time to become fully activated. -
Page 6: Filter Replacement
Filter Tap, or an unpleasant taste or odour in the water. Use only a Zip filter cartridge to match that of your Filter Tap. Replacement cartridges can be obtained through plumbing suppliers or directly from Zip. -
Page 7: Safety Information
Do not install if water pressure exceeds 125 psi (862 kPa). If your water pressure exceeds 80 psi (552 kPa), you must install a pressure limiting valve. Contact a plumbing professional if you are uncertain how to check your water pressure. 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02 Page 7 of 8... -
Page 8: Contact Details
The term “Zip” is a registered trade mark of Zip Heaters (Aust) Pty Ltd. 803828 - Zip Filter Tap - Installation & Operating Instructions - Nov 2015 v1.02 Page 8 of 8...
