Renesas RX13T User Manual

RX13T CPU Card User's Manual
For Your Safety
Do not fail to read this manual before using the RX13T CPU card (RTK0EMXA10C00000BJ) (the product).
• Follow the indications in this manual when using the product.
• This product is an optional board for "Evaluation System for BLDC Motor (RTK0EMX270S00020BJ)" and "24V
Motor Control Evaluation System for RX23T (RTK0EM0006S01212BJ)".
• Keep this manual near the product so you can refer to it whenever necessary.
• Transfer or sale of the product to third parties is prohibited without written approval.
• The purchaser or importer of the product is responsible for ensuring compliance with local regulations. In addition,
the customer is responsible for ensuring that the product is handled correctly and safely, in accordance with the laws
of the customer's country (region).
• All information contained in this manual represents information on products at the time of publication of this
manual. Please note that the product data, specification, sales offices, contents of website, address, etc., are subject
to change by Renesas Electronics Corporation without notice due to product improvements or other reasons. Please
confirm the latest information on Renesas Electronics website.
• The manual for the product, and specification (the documents) are the tool that was developed for the function and
performance evaluation of Renesas Electronics semiconductor device (Renesas Electronics device) mounted on the
product, and not guarantee the same quality, function and performance.
• By purchasing the product or downloading the documents from Renesas Electronics website, the support services
provided from Renesas Electronics is not guaranteed.
Meaning of Notations
In this manual items related to the safe use of the product are indicated as described below.
The degree of injury to persons or damage to property that could result if the designated content in this manual is not
followed is indicated as follows.
Danger
Warning
Caution
Note 1. Serious injury refers to conditions resulting in persistent after-effects and for which treatment would
necessitate hospitalization or regular hospital visits, such as loss or impairment of eyesight, burns
(high- or low-temperature), electric shock, bone fracture, or poisoning.
Note 2. Injury refers to conditions for which treatment would necessitate hospitalization or regular hospital
visits.
Physical damage refers to damage affecting the wider surroundings, such as the user's home or
Note 3.
property.
R12UZ0051EJ0110
2022.2.21
Indicates content that, if not followed, could result in death or serious injury*
to the user, and which is highly urgent.
Indicates content that, if not followed, could result in death or serious injury to
the user.
Indicates content that, if not followed, could result in injury*
3
physical damage.*
User's Manual
R12UZ0051EJ0110
Rev.1.10
2022.2.21
1
2
to persons or
Page 1 of 18
