Quick Installation Guide
欢迎您选购鼎信通达旗下产品！
Thanks For Choosing Dinstar's Products!
安装设备之前请仔细阅读本安装指导。鼎信通达为客户提供全方位的技术支持，需要更多在线
Please read this guide carefully before installing the device. If you need any technical
技术支持，请拨打技术支持热线电话：0755-61919966。
support,
Please contact us
网址：www.dinstar.cn
Tel: +86 755 61919966
Email: support@dinstar.com
Web: www.dinstar.com
UC200 Pro
UC350
UC350
UC350
.
Pro
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dinstar UC200 Pro
Summary of Contents for Dinstar UC200 Pro
- Page 1 Quick Installation Guide UC200 Pro UC350 UC350 UC350 欢迎您选购鼎信通达旗下产品！ Thanks For Choosing Dinstar’s Products! 安装设备之前请仔细阅读本安装指导。鼎信通达为客户提供全方位的技术支持，需要更多在线 Please read this guide carefully before installing the device. If you need any technical 技术支持，请拨打技术支持热线电话：0755-61919966。 support, Please contact us 网址：www.dinstar.cn Tel: +86 755 61919966 Email: support@dinstar.com...
-
Page 2: Description Of Indicators
TF Card Slot FXS Port FXO Port Note: Basically, UC200 Pro is equipped with 2 FXS voice interfaces and 2 FXO voice interfaces. It can be expanded with 2S/2O/1S1O modules, up to support 3 modules. UC350 & UC350 Pro Model... - Page 3 The USB flash drive is inserted USB Indicator The USB flash drive is not inserted The TF card is inserted TF Indicator The TF card is not inserted Description Type Indicators Definition Status There is no power supply or the power supply is abnormal Power Indicator...
- Page 4 Indicators and Ports UC200 Pro Power Port Network Port Console Port Reset Button Power Indicator FXS/FXO FXS/FXO Port Running Indicator Indicator UC350 PORT 0 PORT 1 PORT 2 PORT 3 MCU 1 SLOT2 SLOT3 MCU 0 SLOT0 SLOT1 Main Control Board...
-
Page 5: Installation Attentions
Installation Attentions The adapter of UC200 Pro accepts DC12V 2A power input, and the adapter of UC350 series accepts DC220V 10A dual power input. Please make sure that it is operational and safe. To reduce the interference to telephone calls, please separate power supply cables from telephone lines. To guarantee running of the gateway as usual, please make sure that there ... - Page 6 Connect telephone line to the FXS port and connect PSTN line to the FXO port Converter Converter PSTN Line Telephone Line PSTN Analog Phone Connect to E1/T1 Ports Connect to FXS ports and FXO ports PORT 0 PORT 1 PORT 2 PORT 3 Telephone Line PSTN Line E1/T1 Cable...
- Page 7 Modify PC’s IP Address To log in to the Web Management System of the device, firstly, you need to modify the IP address of the PC that is used to access the device and to make it at the same network segment as the device’s network port of management.
-
Page 8: Login Web Gui
Then enter username and password in the displayed login GUI. The default username and password are admin/admin@123#. Note: The UC200 Pro and UC350 default network port for management is the GE1 port, and the UC350 Pro’s default network port for management is the GE3 port. New devices can only modify the IP address through the management port. - Page 9 Modify Network Configuration You need to modify the IP address of the network ports for service so that the ports and the upstream network are in the same network segment. Firstly, you need to physically connect the device’s network port for management. Then log into the device by entering the IP address of the network port for management in the web browser and click "System->Network"...
- Page 10 Create SIP Extensions Click "Extension ＆ Call Group->SIP Extension" to create the SIP extension: add/delete/disable/enable, etc. UC350 Pro supports batch add or import account files. Note: when add the extension, the profile should be chosen as the corresponding one. After setting, you need to click "apply" to make the settings take effect. The registration status of SIP extension can be checked on the "Extension ＆...
-
Page 11: Add Trunk
Add Trunk SIP Trunk SIP trunks are used to connect other SIP terminals or service providers. When adding a SIP trunk, you should choose corresponding SIP profile based on your current network. The SIP trunk supports UDP/TCP/TLS. You can create a new SIP trunk on the "Trunk ＆ Route->SIP Trunk->Setting" interface, and SIP trunk status can be checked under "Trunk ＆... - Page 12 You can also create Trunk/FXO. It is an alternative to support calls go through or from PSTN. You can set up ISDN PRI/SS7 connections via digital E1/T1 ports. Please be sure that the E1/T1 physical connection is well connected, and PRI status is in up and active status before configuring the call routing.
- Page 13 Configure Inbound / Outbound Route On the "Trunk ＆ Route->Route" interface, you can configure routes for incoming calls and outgoing calls, and select the call Source and Destination addresses for the route. When the configured route is activated, the system will match the route based on the priority index. The key configuration of route is at "condition"...
-
Page 14: Basic Operation
Dial *111# to restart the device; Click "system->Reboot" menu to perform reboot. RST Button (Suitable for UC200 Pro) Under normal running status, if users press RST button for 3 to 6 seconds, the username/password of the device will restore to default username/password, and the network configuration will be restored to...
