Related Manuals for Racing RAC62PR-3
Summary of Contents for Racing RAC62PR-3
- Page 1 ORIGINAL INSTRUCTIONS RIDE-ON LAWN MOWER Model : RAC62PR- 3 WARNING: Please read all instructions carefully before operating the machine! BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France Made in PRC...
- Page 2 Dear Customer, Thank you for having chosen one of our products. We hope that you will get complete satisfaction from using your new machine and that it will fully meet all your expectations. This manual has been compiled in order that you may get to know your machine and to be able to use it safely and efficiently.
-
Page 3: How To Read The Manual
1.1 HOW TO READ THE MANUAL This manual describes various versions of the machine, which mainly differ in: – type of transmission: with either mechanical gear change or continuous speed converter. – the inclusion of components or accessories which may not be available in some areas; –... -
Page 4: Operation
A) TRAINING 1) Read the instructions carefully. Be familiar with the controls and how to use the equipment properly. 2) Never let children or people unfamiliar with these instructions use the machine. Local regulations can restrict the age of the user. 3) Never mow while people, especially children, or pets are nearby. -
Page 5: Maintenance And Storage
2) Mow only in daylight or good artificial light. 3) Before starting the engine, disengage the blades and shift into neutral. 4) Do not use on slopes of more than 10° (17%). 5) Remember there is no such thing as a “safe” slope. Travelling on grass slopes requires particular care. - Page 6 7) If the fuel tank has to be drained, this should be done outdoors. 8) When the machine is to be stored or left unattended, lower the cutting deck. Improper maintenance can reduce life of the tool and create accident and damages. Always bring maintenance.
-
Page 7: Safety Labels
It is suitable only for private use in a garden or plot. Lawnmowers designed for private plots or gardens are those used for the maintenance of grassy areas and private lawns and should not be used in public areas, parks, sports, agricultural or forest areas. 1.3 SAFETY LABELS Your machine must be used with care. -
Page 8: Identification Of The Machine
Danger! Do not near the operational machine WARNING! Do not put hands or feet near rotating parts or under the cutting deck. Contact with the blade(s) can amputate hands and feet. Danger ! Electrical shock ! This symbol indicates the surface is very hot and not touching Guaranteed sound power level 2.1 IDENTIFICATION OF THE MACHINE The identification label located under the seat has the essential... -
Page 9: Fitting The Steering Wheel
18. Labels for regulations and safety: give reminders on the main provisions for working safely, each of which is explained in chapter 1. 19. Engine cover: for access to the engine For storage and transport purposes, some components of the machine are not installed in the factory and have to be assembled after unpacking. -
Page 10: Fitting The Seat
3.3 FITTING THE SEAT Fit the seat (1) onto the plate (2) using the screws (3) 3.4 FITTING THE BLADE ENGAGEMENT LEVER Fit the end of the lever (1) on the projecting part of the pin (2) and fix it all by tightening the screw (3) and nut (4) 3.5 CONNECTING THE BATTERY 1. -
Page 11: Fitting The Grass-Catcher
3.6 FITTING THE GRASS-CATCHER Identify the screws to be used by following the drawing that shows them in their actual Size Fit the two tie rods (1) and fasten them by using the screws (2) 3.7 FITTING THE DEFLECTOR... -
Page 12: Steering Wheel
4.21 4.6.1 4.11 4.12 4.1 STEERING WHEEL Turns the front wheels. 4.2 CLUTCH / BRAKE PEDAL This pedal has a double function: during the first part of its travel it acts as a clutch, engaging and disengaging drive to the wheels, and in the second part it works the brake. Do not keep the pedal half way of clutch engagement or disengagement, as this can cause overheating and damage the... -
Page 13: Parking Brake Lever
4.3 PARKING BRAKE LEVER This lever stops the machine from moving when it has been parked. There are two positions: 4.3 PARKING BRAKE LEVER This lever stops the machine from moving when it has been parked. There are two positions: –The brake is engaged by pressing the pedal (☛4.2) right down and moving the lever to position «B». -
Page 14: Key Ignition Switch
4.6 LEVER ENGAGEMENT AND BRAKE OF BLADE The lever has two positions, as shown on the plate: –If the blade is engaged when safety conditions have not been complied with, the engine shuts down and cannot be restarted ( ☛5.2). –... - Page 15 «CHOKE» (if fitted) = cold starting «FAST» for maximum engine speed «SLOW» for minimum engine speed –The «CHOKE» position (if fitted) enriches the mixture so must only be used for the necessary time for cold starting. – When moving from one area to another, put the lever in a position between «SLOW» and «FAST».
-
Page 16: Safety Recommendations
– Disengage the blade. – Put the lever in a P parking block. – Hang up the grass-box 5.1 SAFETY RECOMMENDATIONS The machine must only be used for the purpose for which it was designed (cutting and collection of grass). Using the machine in any other way is considered "improper use"... -
Page 17: Why The Safety Devices Cut In
This machine must not be used on slopes greater than 10° (17%) ( ☛ 5.5). All the references relating to the positions of controls are those described in chapter 4. 5.2 WHY THE SAFETY DEVICES CUT IN The safety devices work in two ways: –... -
Page 18: Tire Pressure
5.3.2 Tire pressure Having the correct tire pressure is essential for ensuring that the cutting deck is perfectly horizontal and thus mows evenly. 1. Unscrew the valve caps; 2. Connect a compressed air line with a gauge to the valves and adjust the pressure to the indicated values. - Page 19 To refuel (to be done when the machine has stopped): 1. unscrew the plug (4) from the tank located behind the seat; 2. refuel using a funnel, but do not completely fill the tank. The tank's capacity is about 1.1 liters; 3.
-
Page 20: Using The Machine
5.4 USING THE MACHINE 5.4.1 Starting the engine all starting operations have to be effected in an open or well-ventilated area! ALWAYS REMEMBER THAT EXHAUST GASES ARE TOXIC! To start the engine: 1. sit on the seat and press the brake pedal right down(☛4.3); 2. -
Page 21: Starting And Moving Without Mowing
5.4.2 Starting and moving without mowing this machine has not been approved for use on public roads. It has to be used (as indicated by the Highway Code) in private areas closed to traffic. When moving the machine, the blade must be disengaged and the cutting deck put at its highest position. -
Page 22: Grass Cutting
5.4.5 Grass cutting The machine is not designed for heavy duty use or for mowing large quantities of grass. The blade is engaged by means of a clutch device. To avoid damage or premature wear of the friction elements, strictly observe the following instructions. -
Page 23: Emptying The Grass-Catcher
5.4.6 Emptying the grass-catcher The grass-catcher is full when the grass cuttings remain on the lawn. If you continue mowing with the grass-catcher full, it may block the collector channel. To empty the grass-catcher: 1. lower the engine speed; 2. go into neutral (N) (☛4.4) and stop the machine’s forward movement;... - Page 24 To keep the battery charged, do not leave the key in the «ON» position when the engine is not running. 1. shift the accelerator lever to «OFF». Always make sure that the accelerator level is in the «OFF» position before leaving the machine unattended 5.4.10 cleaning the machine After each mowing, clean the outside of the machine, empty the grass-catcher and shake it to remove residual grass and earth.
- Page 25 6. engage the blade and leave it to turn for a few minutes. Take off the grass-catcher, empty and rinse it, then put it in a position where it can dry quickly. b) To clean the upper part of the cutting deck: –...
-
Page 26: Using On Slopes
5.5 USING ON SLOPES When mowing lawns on a slope, observe the maximum gradients already mentioned (max 10° - 17%) and move up and down but never across them. Take great care when changing direction that the highest wheels do not hit obstacles (such as stones, branches, roots, etc.) that may cause the machine to slide sideways, tip over or otherwise cause loss of control. -
Page 27: Advice On How To Obtain A Good Cut
5.7 ADVICE ON HOW TO OBTAIN A GOOD CUT 1. To keep a lawn green and soft with a good appearance, it should be cut regularly without damaging the grass. 2. It is always better to cut the grass when dry. 3. -
Page 28: Routine Maintenance
Never use the machine with worn or damaged parts. Faulty or worn-out parts must always be replaced and not repaired. Only use original spare parts: The use or non-original and/or incorrectly fitted parts will compromise the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is under no circumstance liable or responsible. -
Page 29: Interventions On The Machine
6.2.3 Battery To ensure long life to the battery it is essential to keep it carefully maintained. The machine battery must always be charged: – before using the machine for the first time after purchase; – before leaving the machine for a prolonged period of disuse; –... -
Page 30: Replacing Wheels
6.3.2 Replacing wheels 1. Place the machine on a flat surface and put blocks under a load-bearing part of the frame on the side of the wheel to be changed; 2. using a screwdriver, remove the snap ring (1) and the washer (2);... - Page 31 A blown fuse must always be replaced by one of the same type and ampere rating, and never with one of another rating. If you cannot find out why the fuse has blown, consult a Licensed Service Centre. The electric system and the card are not protected by any fuses. If the safety system fails to work properly or there are engine problems due to the electric system, contact a Licensed Service Centre.
- Page 32 PROBLEM LIKELY CAUSE SOLUTION 1.With the key on «START» Electronic card blocked due to: Turn the key to «STOP» and look for the cause the starter motor of the problem: does not run – flat battery – recharge battery (☛6.2.3) –...
- Page 33 4. The engine does not start – earth connections of the micros witches –check connections disconnected – you are not ready for starting –check that the conditions allowing the start are met (☛5.2.a) 5. The engine stops –earth connections of the micro switches –check connections Disconnected 6.
- Page 34 1. BATTERY-CHARGER (on request) Battery charger charges the battery when the machine is in storage. Note: The motor can be started manual (without battery) and the Battery will be charged automatically if the motor is working. 2. Change Blade 1.Make sure there is no machine oil and gasoline in the tank, side lay the machine as the picture above.
- Page 35 Maximum noise and vibration levels Operator ear noise pressure level (according to regulation ISO 5395-1:2013, Annex F) ......79.6dB(A) – Measurement uncertainty (2000/14/EC) ....2.5dB(A) Measured acoustic output level (according to directive ISO 5395-1:2013, Annex F) …… 94.34dB(A) – Measurement uncertainty (2000/14/EC) ....1.08 dB(A) Guaranteed acoustic output level (according to directive ISO 5395-1:2013, Annex F) …..98 dB(A) Vibration level...
-
Page 37: Declaration Of Conformity
ZI, 32 rue Aristide Bergès – 31270 Cugnaux – France Tel : +33 (0)5.34.502.502 Fax : +33 (0)5.34.502.503 declares that the machines: RIDE-ON LAWN MOWER RAC62PR-3 Serial No.: 20210103055-20210103486 20210126290-20210126309 the people name holding the technical file：Mr. Olivier Patriarca have been designed in compliance with the following standards: EN-ISO 5395-1:2013+A1: 2018, EN-ISO 5395-3:2013+A1:2017+A2:2018 EN-ISO 14982：2009... -
Page 38: Warranty
12. WA R R A N T Y WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. -
Page 39: Product Failure
13. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 40: Warranty Exclusions
14. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
