Directed Directechs DS3 Installation Manual page 9

Module
Conn./Pin Color Description
H3/9 Lt. Green/White Relay N.C. No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM (+) Parking Light Output
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87A)
H4/4 Pink/White (+) Accessory 2 Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Disable (conn. side) [3]
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory 1 Output
H4/9 Red/White (+) 12 Volt Input
H4/10 Pink (+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
9 933.FORD1 4.17.193.2 2005 Mercury Grand Marquis
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
LCM right of steering column, black 16 pin plug, pin 4
Ignition Switch, gray 10 pin plug, pin 9
Connects To
Wire Location
No Connection
Ignition Switch, gray 10 pin plug, pin 9
No Connection
Ignition Switch, gray 10 pin plug, pin 6
Ignition Switch, gray 10 pin plug, pin 9
Ignition Switch, gray 10 pin plug, pin 10
Connection required for Starter Disable ONLY.
Ignition Switch, gray 10 pin plug, pin 10
Ignition Switch, gray 10 pin plug, pin 7
Ignition Switch, gray 10 pin plug, pin 9
Ignition Switch, gray 10 pin plug, pin 1
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-) Wire Color
(chassis ground)
+ brown
+ Red (25A)
(+/-) Wire Color
+ Red (25A)
+ White/Lt. Blue
+ Red (25A)
+ Dk. Green
+ Dk. Green
+ Gray/Yellow
+ Red (25A)
+ Violet/Orange
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
(+/-) Wire Color
Connection
Mandatory
Mandatory
Mandatory
Connection
Mandatory
Remote Start
Only
Remote Start
Only
Mandatory
Mandatory
Mandatory
Remote Start
Only
Mandatory
Connection
