- Page 1 ® NuStep Upper Body Ergometer u se r m a n u al...
-
Page 3: Table Of Contents
Contents Introduction ..................4 Safety Instructions ................5-6 Installation and Placement ..............7 AC Adapter Use ................... 8 UE8 Feature Overview ................ 9 Making Adjustments ..............10-12 Correct Riding Position ..............13 Display Screens................14-16 Pause Function.................. 17 System Settings................. 18 User Settings .................. -
Page 4: Introduction
Introduction Thank you for purchasing the NuStep UE8 upper body ergometer. We appreciate your business and your confidence in our products. The new upper body ergometer line, which includes the UE8 the UE8 , continues NuStep’s tradition of innovation and its mission to develop inclusive exercise equipment that can benefit users of virtually all fitness levels and functional abilities. -
Page 5: Safety Instructions
Safety Instructions CAUTION WARNING This is the safety alert CAUTION indicates a WARNING indicates a symbol. It is used to call potentially hazardous potentially hazardous attention to instructions situation, which if not situation, which, if not concerning personal avoided, may result avoided, could result in safety. - Page 6 This product may be used by persons with reduced physical, sensory Do not lift this product by yourself. The or mental capabilities, or lack of UE8 is very heavy. It weighs 320 lbs. experience and knowledge if they are (145 kg). supervised by a person responsible...
-
Page 7: Installation And Placement
Installation and Placement Unpacking and Installation To ensure safe and effective operation of your UE8, place on a flat, stable surface. Adjust Carefully unpack the UE8 from the shipping leveler feet as required. container and transport the product to the installation location. -
Page 8: Ac Adapter Use
AC Adapter Use The UE8 is powered by an AC adapter which is included with the equipment. The AC adapter may be plugged into either the front or the rear jack.* Plug the adapter into an appropriate power outlet. Route the AC adapter power cable in a manner that prevents tripping hazards and prevents damage to the adapter. -
Page 9: Ue8 Feature Overview
UE8 Feature Overview Height Display Console Adjustment Arm Swivel Seat Release Lever Leveler Feet Seat Adjustment Swivel Drivetrain Seat Recline Release Lever Body Release Lever Dual-screen Display Console Arm Cranks Arm Height Body Swivel Adjustment Lever Adjustment Lever... -
Page 10: Making Adjustments
Making Adjustments Swivel Seat Operation 1. Place feet firmly on the rail or floor. 2. Lift the rear release lever to unlock seat. 3. Swivel the seat in either direction (seat swivels 360˚ and locks every 45˚). 4. Release the lever to lock seat in position. NOTE: The seat can be rotated with or without a user on the machine. - Page 11 Making Adjustments Adjust Seat Recline 1. Place feet firmly on the rail or floor. 2. Lift the black lever on left side of seat to unlock. 3. Push on seat back to increase recline (up to 12˚ recline possible). 4. Release lever to lock seat in place. Lift black lever on left side.
- Page 12 Making Adjustments Adjust Arm Height 1. Locate the square silver lever on the underside of the Height Adjustment Arm. 2. Pull the lever toward you to unlock. 3. Move the arm up or down. 4. Release the lever to lock in position. Pull square lever toward you to unlock adjustment arm.
-
Page 13: Correct Riding Position
Correct Exercise Positions Exercisers can access and use the UE8 from three positions: seated, standing or a wheelchair. The exerciser’s body position and the physical configuration of the machine will vary depending on the needs and goals of the exerciser. -
Page 14: Display Screens
The UE8 has a Home screen and Metric screen with touchscreen navigation: Home screen: Displays workout apps NuStep Charts, Pace Partner, Balanced Power, Trail Runner and Quick Start (not shown). Tap an app icon to launch. Metric screen: Displays all workout... - Page 15 Pace Partner Users set a target pace and a workout metric (SPM, Watts or METs). Goal is to keep current pace at the target pace. To set goals: • Tap to open Your Target Pace screen Use slider to set pace. Tap on desired metric.
- Page 16 Trail Runner Plays videos of scenic waterways to engage users as they work out. To start: • Tap to select desired video • Cycle the arms to play video To return to the Trail Runner menu: • Tap screen - the title bar drops down •...
-
Page 17: Pause Function
The UE8 has a 3-minute console shutdown. If a user stops the arm rotations and does not resume within three minutes, the console will reset. Before the console shuts down, the user has the option to extend the pause (e.g., for interval training) for an additional 15 minutes. -
Page 18: System Settings
System Settings Use to adjust volume and screen brightness, change default settings, view diagnostics, change metric configuration, view regulatory and software information. Slide to adjust. Slide to adjust. Admin Use to change default settings (age, weight, gender). Changes made to the default settings are global. - Page 19 3. Go to the Metric screen. 4. Tap to open the Reset Workout screen. 5. Tap Reset to apply changes. Diagnostics The diagnostics screens display live and historical data for service technicians or those responsible for equipment maintenance. The Historical and Versioning screen requires a password to access.
- Page 20 User Configuration Users can create and save a profile with their own settings. To create: 1. Tap screen to open numeric keyboard. 2. Enter age, weight and select sex.
-
Page 21: User Settings
Users can export their profile data to a USB drive at any time. USB port To export: 1. Insert USB drive into the USB port on the back of the display console. 2. Tap on the Metric screen to open the User Settings screen. NOTE: Skip this step if the profile screen launches automatically. -
Page 22: Exporting Workout Summary
Exporting Workout Summary Users can export their workout summary to a USB drive. The summary is saved in a PDF format. NOTE: If the user intends to export their summary, insert USB drive into the USB port on the back of the console before they begin. At the end of a workout (when the user has stopped cycling the arms) the Step to Unpause screen will open. -
Page 23: Preventive Maintenance
Preventive Maintenance Preventive Maintenance Intervals The UE8 is a high quality, durable piece of equipment designed for commercial use. A few tasks are recommended to ensure safe operation and increase the useful life of the product. Please follow the recommended preventive maintenance intervals according to the amount of usage that the product receives. -
Page 24: Warranty And Serial Number Information
UE8 Warranty To view or print your warranty, go to: www.nustep.com If you have any questions about your warranty, please contact Customer Service at: 800-322-4434 or support@nustep.com. Customers outside the United States and Canada may obtain warranty information from the local distributor in the country where the product was sold. -
Page 25: Obtaining Customer Service And Parts
For assistance with your UE8 unit, please contact NuStep Customer Service. Please have the serial number of the unit (located on the right side of the rear support cover) and a complete description of the problem so our product specialists can better assist you. -
Page 26: Technical Data
Braking system and cycling action The UE8 features a speed-independent braking resistance system. Marks AC Adapter The UE8 is only to be used with the power supply provided with the unit. Model GlobTek TR9KI3750CCP-IM(R6B) Class 2 Output Rating: 24 Vdc 3.75A, 90W Input Rating: 100 –... -
Page 27: Us Fcc Compliance
US FCC Compliance US FCC Compliance Statement: Note: This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can generate radio frequency energy and, if not installed and used in accordance with the installation instructions, may cause harmful interference to radio communications. - Page 31 No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose without the express written permission of NuStep, LLC. © Copyright February 2021 by NuStep, LLC.
