4
• Plug power cord into properly grounded
Step
Connect
Power
5
To raise the vent, press the RAISE/LOWER
switch.
Step
Install Filters,
Check
Operation
• Tip filter into the opening and pull straight
• Slide the filter to the right side.
• Tip the other filter into the opening and
• To turn the fan on, slide control to HIGH.
Note: It is not necessary to turn the fan OFF
before lowering the vent. The fan will auto-
matically turn off when the vent is lowered.
When the fan is not turned off before lower-
ing the vent, it will automatically come on at
the previously set speed when the vent is fully
raised.
To lower the vent, press the RAISE/LOWER
switch and hold until the vent begins to lower.
receptacle.
– On 30" models, the switch is located on the
top right side of the vent.
– On 36" models, the switch is installed in a
separate location.
down so that the filter rests on slides.
pull straight down.
– Select desired speed by sliding control
between HI and LO settings.
Installation
Downdraf t Vent Systems
17
