Before you begin-Read these instructions completely and carefully.
IMPORTANT: Save these instructions for local inspector's use.
IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer: Be sure to leave these instructions with the Consumer.
Note to Consumer: Keep these instructions with your Use and Care Book for future reference.
This appliance must be properly grounded. See "Power Supply", page 12.
CAUTION
WARNING
If you have a question concerning the installa-
tion of this product, call the GE Answer
Center® Consumer Information Ser vice at
800.626.2000, 24 hours a day, 7 days a week.
If you received a damaged vent, you should
immediately contact your dealer or builder.
Proper installation is the responsibility of the
installer. Product failure due to improper
installation is not covered under the GE
Appliance Warranty. See the Use & Care
Guide for warranty information.
For Monogram local service in your area,
1-800-444-1845.
For Monogram service in Canada,
1-888-880-3030.
For Monogram Parts and Accessories, call
1-800-626-2002.
WARNING:
To reduce the risk of fire, electric shock, or
injury to persons, observe the following.
A. Use this unit only in the manner intended
B. Before ser vice or cleaning unit, switch
Contents
Design Information
Models Available ........................................................... 3
Accessories ..................................................................... 3
Product Dimensions ..................................................... 3
Advance Planning ..................................................... 4, 5
Installation Preparation
Cutouts for Monogram Cooktops ................. 6, 7, 8 , 9
Clearances .................................................................... 10
Tools and Materials Required .................................... 10
Parts Supplied ............................................................. 10
Remove Packaging ...................................................... 11
Power Supply ............................................................... 11
Venting Options .................................................... 12, 13
2
by the manufacturer. If you have questions,
contact the manufacturer.
power off at service panel and lock the
service disconnecting means to prevent
power from being switched on accidentally.
When the service disconnecting means
cannot be locked, securely fasten a promi-
nent warning device, such as a tag, to the
service panel.
• Do not attempt to repair or replace any part
of the downdraft system unless it is specifi-
cally recommended in this book. All other
servicing should be performed by a quali-
fied technician.
• For general ventilating use only. Do not use
the exhaust hazardous or explosive materials
and vapors.
• Installation work and electrical wiring must
be done by a qualifed person(s). In accor-
dance with all applicable codes and stan-
dards including fire-rated construction.
To reduce the risk of fire and to properly
exhaust air, be sure to duct air outdoors. Do
not vent exhaust air into spaces within walls or
ceilings or into attics, crawl spaces or garages.
WARNING: TO REDUCE THE RISK OF
FIRE, USE ONLY METAL DUCTWORK.
Do not attempt to repair or replace any part
of the downdraft system unless it is specifically
recommended in this book. All other servic-
ing should be performed by a qualified
technician.
Ductwork
Duct Fittings ................................................................ 14
Installation
Step 1, Install Downdraft Vent ................................... 15
Step 2, Install the Ductwork ....................................... 15
Step 3, Install Raise/Lower Switch ............................ 16
Step 4, Connect Power ............................................... 17
Step 5, Install Filters, Check Operation .................... 17
Accessories
JXRB57 Kit for Indoor Remote Blower Locations ... 18
JXBC57 Kit for Outdoor Remote Blower Locations 21
Cleaning ....................................................................... 25
