• Use electrical cable and connectors that
Step
Connect
• Attach the wire box removed from the
Electrical
• Use wire nuts to secure the wire to the 3"
• Insert the plug into the mating plug on the
• Reinstall wire box with original screws.
6
• Mount the blower onto the mounting plate.
Step
• Install damper to bottom of outlet with 4
Mount
Blower
• Place the cover over the the assembled kit
7
Step
Finalize
Installation
conform to local codes (14 gauge min. is
recommended). Use a length to reach
between the vent and the blower/motor
location.
blower conduit to the end of new wiaring.
remaining wires with plug.
vent.
Secure with original nuts.
screws.
and secure with 16 screws.
JXBC57 Kit
For Outdoor Remote Blower Locations
Plenum
Provided
Mounting
Screws
Blower
Wire
Box
Wiring to Blower Junction Box
3-Wire
Connectors
Wire Nuts
