Clearances; Tools And Materials Required; Parts Supplied - GE Monogram ZVB36 Installation Instructions Manual

Caution: Wall coverings,

Clearances

countertops and cabinets
should withstand 200° heat
generated by any cooktop.
Min. 18"
Electric Cooktop Models
• Large flat-blade screwdriver.
Tools and
• Jig saw
Materials
• Carpenter's square
Required
• Ductwork to suit the installation
Open the carton and remove parts package.
Parts
Check contents to be sure all pieces are
Supplied
present.
13"
Max.
30"
Min.
2" Min. to
Wall When
Installed
Remote Raise/Lower Assembly
Wire box and screws Plastic Strain Relief
Switch Cover Plate
Attachment Bracket
Installation Preparation
Gas - 8-13/16" min.
Electric - 2"
Clearance to Sidewall
13"
Max.
30"
Min. 18"
Min.
2" Min. to
Wall When
8" Min. to
Installed
Wall When
Installed
Gas Cooktop Models
Wire and White Connector
Downdraf t Vent Systems
8" Min. to
Wall When
Installed
4 Stablizing Brackets
10
