• The base is designed to be mounted to studs
Step
Mark
– Or Place the base against the exterior wall
Mounting
Location
• The bottom of the base assembly must be
• Cut a 6-1/8" dia. hole in the vertical struc-
• Drill 6 pilot holes through the wall for the
CAUTION: When cutting or drilling into a wall or ceiling,
do not damage electrical wiring or hidden utilities.
Check for interference with floor joists and stud walls. If
necessary, locate the base to provide a secure
installation.
• Place a 6" round duct through the hole
3
• Flatten the shipping box to use as a pad.
• Place the unit on its back onto the protective
Step
• Remove the wire box on the plenum.
Prepare
• Cut the blower leads approximately 3" from
the Vent
• Remove the blower conduit by loosening the
• Set aside the 3" wire leads with plug, wire
on 16" centers. Use the dinensions shown to
determine the location of the ducting and
wiring through the wall.
and mark the 6 mounting locations, the 6"
duct location and the hole for the wiring.
Use pencil or chalk.
10" min. above the ground. There should be
no obstructions to the discharge from the
damper.
ture to accommodate a 6" round duct
another hole for the wiring.
6/16" fasteners.
extending approximately 3" from the wall to
provide a proper seal with the blower.
Secure the duct to the building structure to
prevent it from being pushed back when the
blower is installed.
pad.
the plug on the end of the vent.
screw on the fitting.
box and screws.
JXBC57 Kit
For Outdoor Remote Blower Locations
16"
6-11/16"
Align
With Duct
Opening
On Outside
Wall
12-15/16"
1-13/16"
Blower Wire Box
Loosen
Screw
Blower Conduit
6 Holes
For 5/16
Fastners
4-3/4"
6"
12"
10" Min
Above Ground
3"
