Operation, cont'd
4. Release the Wipe button and, while the button remains lit,
rotate the Adjust knob to set the amount of seconds that
the sub-effect will appear on the screen. You can set the
duration of the PIP sub-effect in increments of tenths of a
second, 0.0 to 0.5 seconds.

Switching with a transition sub-effect

After you have set up a transition sub-effect and its duration, do
the following to execute a transition from the preview input to
the program input and vice versa:
• Press the Take button.
-or-
Move the T-bar up or down to manually control the effect.
•
In Wipe mode, the button blinks while the transition is taking
place.
In PIP mode, the button continues to blink while the PIP
window is open. To close the window, press Cut or Take, or
slide the T-bar all the way up or down.

Using the Picture Controls

The picture controls allow you to adjust the centering, size,
detail, contrast/brightness, and color/tint of the preview image.
1. Select a preview input by pressing one of the Preview
Input buttons (buttons 1 through 6).
2. Press the desired Picture Controls button. The button
lights.
3. While the button is lit, rotate the H and/or V knob to make
your adjustment(s).
4. To exit the picture control, wait for the button's light to go
out, or press another Preview Input, Picture Controls, or
Transition Effects button.

Adjusting color and tint

1. Press and release the Color/Tint button. The button lights.
2. While the Color/Tint button is lit,
• Rotate the H Adjust knob to change the color.
• Rotate the V Adjust knob to change the tint.
RCP 2000 with ISS 506 Support • Operation
3-16

Adjusting contrast and brightness

1. Press and release the Cont/Bright button. The button
lights.
2. While the Cont/Bright button is lit,
• Rotate the H Adjust knob to change the contrast.
• Rotate the V Adjust knob to change the brightness.

Sizing an image

1. Press and release the Size button. The button lights.
2. While the Size button is lit,
• Rotate the V Adjust knob to adjust the vertical size
(height).
• Rotate the H Adjust knob to adjust the horizontal size
(width).

Resizing in PIP mode

To resize the image and/or the PIP window while the RCP is
in PIP mode,
1. Press the Size button once to enable window resizing.
2. Press the Size button again as needed to toggle between
PIP window size adjustment and image size adjustment.
3. Rotate the H and V Adjust knobs to adjust the width and
height of the PIP window or the image.
The Size button stays lit steadily while you are adjusting
the PIP window size and blinks while you are adjusting the
image size.

Centering an image

To position the image on the screen,
1. Press and release the Center button. The button lights.
2. Rotate the V Adjust knob to adjust the image position
vertically.
3. Rotate the H Adjust knob to adjust the image position
horizontally.

Centering in PIP mode

To adjust the position of the image and/or the PIP window
while the RCP is in PIP mode,
1.
Press the Center button once to enable window centering.
2. Press the Center button again as needed to toggle between
PIP window positioning and image positioning.
RCP 2000 with ISS 506 Support • Operation 3-17
