6. CABLE CONNECTION PARAMETERS

The wiring details are as below:
100FX Fiber Optical Cables:
■
Standard
100Base-FX
(1300nm)
100Base-FX
(1310nm)
100Base-BX-U
(TX :1310/RX :1550)
100Base-BX-D
(TX :1550/RX :1310)
1000X Fiber Optical Cables:
Standard
1000Base-SX
(850nm)
1000Base-LX
(1300nm)
Wiring Distances:
Standard Fiber
1000Base- MM
SX
1000Base- MM
LX
SM
The Single-mode port (1000Base-LX port) of
Notice
kilometers and provides additional margin allowing for a 10/20/30/60/70 kilometer
Gigabit Ethernet link on single mode fiber.
Fiber Type
Multi-mode
Multi-mode
Single-mode
Single-mode
Fiber Type Cable Specification
Multi-mode 50/125μm or 62.5/125μm
Multi-mode 50/125μm or 62.5/125μm
Single-mode 9/125μm
Diameter (micron) Modal Bandwidth (MHz *
km)
62.5 100
62.5 200
50 400
50 500
62.5 5
50 4
50 5
9 N/A
Cable Specification
50/125μm or 62.5/125μm
50/125μm or 62.5/125μm
9/125μm
9/125μm
MC350-4T-2S
30
Max. Distance (meters)
220
275
500
550
550
5000*
complies with LX 5
