2.1.2 LED Indicators

System
LED Color Function
Lit: indicate power 1 has power.
P1 Green
Lit: indicate power 2 has power.
P2
Green
Lit: indicate either power 1 or power 2 has no power.
FAULT
Green
Per 10/100/1000T Ports
LED Color Function
Lit: indicate the link through that port is successfully established at 100Mbps or
100
Orange
10Mbps.
LNK/ACT
Blink: indicate that the Switch is actively sending or receiving data over that port.
Off: indicate the link through that port is successfully established at 1000Mbps.
Lit: indicate the link through that port is successfully established at 1000Mbps or
1000 Green
10Mbps.
LNK/ACT
Blink: indicate that the Switch is actively sending or receiving data over that port.
Off: indicate the link through that port is successfully established at 100Mbps.
Per 100 / 1000X SFP Slots
LED Color Function
Lit: indicate the link through that port is successfully established at 100Mbps or
LNK/ACT Green
1000Mbps.
Blink: indicate that the Switch is actively sending or receiving data over that port
or the port operate.
11
