1000Base-SX/LX:
Before connecting the other switches, workstation or Media Converter, please do the following:
1. Set the DIP Switch of SFP Port 1 or Port 2 to the "OFF" position with fiber speed 1000Base-X.
Port 5 (DIP 1)
Port 6 (DIP 2)
2. Make sure both sides of the S30/SXX SFP transceiver are with the same media type, for example: 1000Base-SX to
1000Base-SX, 1000Base-LX to 1000Base-LX.
3. Check whether the fiber-optic cable type matches with the SFP transceiver model.
To connect to 1000Base-SX SFP transceiver, use the Multi-mode fiber cable, with one side being the male
duplex LC connector type.
To connect to 1000Base-LX SFP transceiver, use the Single-mode fiber cable, with one side being the male
duplex LC connector type.
Connecting the fiber cable
1. Attach the duplex LC connector on the network cable into the SFP transceiver.
2. Connect the other end of the cable to a device – switches with SFP installed, fiber NIC on a workstation or a Media
Converter.
3. Check the LNK/ACT LED of the SFP slot on the front of the Industrial Gigabit Ethernet Switch. Make sure that the
SFP transceiver is operating correctly.
100Base-FX:
Before connecting the other switches, workstation or Media Converter, please do the following:
1. Set the DIP Switch of SFP Port 1 or Port 2 to the "ON" position with fiber speed "100FX".
Port 5 (DIP 1)
Port 6 (DIP 2)
2. Make sure both sides of the SFP transceiver are with the same media type or WDM pair, for example, 100Base-FX
to 100Base-FX, 100Base-BX20-U to 100Base-BX20-D.
3. Check whether the fiber-optic cable type matches with the SFP transceiver model.
To connect to S35/S25 SFP transceiver, use the multi-mode fiber cable, with one side being the male duplex
LC connector type.
To connect to S35/S25 SFP transceiver, use the single-mode fiber cable, with one side being the male duplex
LC connector type.
Connect the fiber cable
1. Insert the duplex LC connector on the network cable into the SFP transceiver.
2. Connect the other end of the cable to a device, switches with SFP installed, to fiber NIC on a workstation or a Media
Converter.
OFF
ON
100FX
1000X
100FX
1000X
ON
100FX
100FX
OFF
1000X
1000X
