Extron electronics AVTrac Demonstration Kit Setup Manual

Setup Guide for AVTrac
The AVTrac Demonstration Kit shows how the AVTrac system meets customers' application needs. The kit components
can be unpacked from the carrying box as shown in the figures below. To repack the kit, reverse the steps.
The illustrations below show the US version of the AVTrac Demonstration kit. The International and Universal
N
models are similar in size and packaging, but contain a single AC outlet, which may be connected to double insulated
power cable, or flex conduit without wires.
If the box is to be reused, remember to save
N
the packing foam.
This kit is for demonstration
W
purposes only. The AC power module is not
wired to distribute power and must not be
connected to an electrical power source.
1. Remove carpet pieces.
2. Remove top foam and foam
covering side ramps.
3. Remove side and end ramps.
4. Remove track pieces and
connectivity box with AC
conduit.
Demonstration Kit
™
Pre-cut
Carpet Pieces (2)
Connectivity Box (1)
End Ramps (2)
AC Conduit (1)
Side Ramps (2)
Carpet Finish
Cover Track (1)
Rubber finish
Cover Track (1)
Base Track (1)
68-1530-01
Rev. B 02 09
