Quick Start Guide — IPL T CR48
To install and set up an IPL T CR48 interface, follow these steps:
Step 1
Turn all of the equipment off and disconnect it from the power
source.
Projector
Step 2
Mount the IPL T CR48 interface near a screen, screen lift, lighting
system, or projector lift, as illustrated below.
Step 3
Attach the network (LAN) cable to the IPL T CR48 unit and to a host
PC, switch, hub, or router. See Ethernet connection in chapter 3 for
more information on this connection.
Extron IPL T CR48 Ethernet Control Interface
Projector
Lift
Control
Mounting
Bolt
IP L
1U Rack Shelf
1/4 Rack Width False Front
Face Plate
Use 2 mounting holes on
opposite corners.
00-05-A6-00-00-01
POWER
LAN
12V
0.5A
IPL T CR48 • Quick Start Guide
