EverFocus 350HQ User's Manual And Operation Instructions

EverFocus 350HQ User's Manual And Operation Instructions

High resolution weatherproof camera
Hide thumbs Also See for 350HQ:

Advertisement

Quick Links

Download this manual See also: User's Manual and Operating Instructions, User Manual
H
i
g
h
R
e
s
o
H
i
g
h
R
e
s
o
l
u
t
i
o
n
W
e
l
u
t
i
o
n
W
e
User's Manual
Operation Instructions
E
Z
S
E
Z
S
a
t
h
e
r
p
r
o
o
a
t
h
e
r
p
r
o
o
and
e
r
i
e
s
e
r
i
e
s
f
C
a
m
e
r
a
f
C
a
m
e
r
a

Advertisement

loading
Need help?

Need help?

Do you have a question about the 350HQ and is the answer not in the manual?

Questions and answers

Related Manuals for EverFocus 350HQ

Summary of Contents for EverFocus 350HQ

  • Page 1 User’s Manual Operation Instructions...
  • Page 2 Notice This manual is presented to the users of EZ series by EverFocus Electronics Corp. With years of engineering researches, EverFocus has spared no effort to provide the high quality products to the worldwide users. For the policy of continual product improvement, EverFocus reserves the right to make changes to the product specifications and documentation without notice.

  • Page 3: Table Of Contents

    Table of Contents Safety Warning … … … … … … … … … … … … … … .. 1 Introduction… … … … … … … … … … … … … … … … . 2 Specification… … … … … … … … … … … … … … … … 3 Major Parts Names…...

  • Page 4: Safety Warning

    1. Handle the camera with care. Be careful when handling the camera, do not drop it or subject it to strong shock or vibration to prevent any damages to it. Do not disassemble it or place it on an unstable base. 2.

  • Page 5: Introduction

    The new EZ series offers great performance in 1/3”image format color CCD camera. The EZ series is ideal for outdoor applications such as parking lots, gas stations or shopping malls. The sophisticated circuit design provides a heater that turns on at 10℃ for cold weather. The EZ series will provide protection against the elements and provide an excellent quality picture.

  • Page 6: Specification

    Weather proof rate Power source: Power Consumption: 5W max, 15W when heater is active Dimension: Operating temperature: Specification 350HQ 1/3” interline transfer CCD NTSC: 768(H) x 494(V) PAL: 752(H) x 582(V) 0.5lux/F=1.2; 1.43lux/F=1.6 1.0Vp-p, 75 ohm Vari-focal lens f=3.8~9.5mm / Vari-focal lens f=3.7~12mm...

  • Page 7: Major Parts Names

    Major Parts Names and Their Functions Back Fixing Plate Back Fixing Plate Sun Shield Sun Shield Cover Cover Fixing Screw Fixing Screw IRIS ALC/Level Adjustment IRIS ALC/Level Adjustment Focus Zoom Focus Zoom Lens Lens Heater Heater Swivel Swivel Screw Screw Set-Screw Assembly Assembly...

  • Page 8: Installation Instructions

    Installation Instructions 1. Using the supplied screws, mount the bracket base on the desired location. 2. Connect the BNC connector of the camera to a monitor or other video device through a 75 ohm type coaxial cable with BNC female connector at cable extension.
  • Page 9 g. When all the adjustments and settings are completed, overlaying the cover gently. Be careful not to damage to the “O”-Ring and camera components. h. To reassemble the sun shield, match the hole on the sun shield to the back fixing plate of camera, Fix the screw on the front fixing plate. Make sure the wider side of the fixing plate holds the edge of the camera well.

  • Page 10: Settings

    The camera is set up at factory and normally requires no adjustments. Sometimes, however, adjustments may be necessary. Please refer to the following description for the function details. ??The IRIS ALC and IRIS Level adjustments are located on the side circuit board, use a screwdriver to adjust if it’s necessary.
  • Page 11 ??The 4 control switches are also located on the side circuit board, the switches in orders are for Flickerless, Back Light Comp, Auto Gain Control and Line Lock. Normal Normal FL(Flickerless) Normal/On When picture flicker fiercely, turn FL on, then the camera will stabilize the speed of electronic shutter at 1/100(NTSC) or 1/120(PAL) automatically, and reduce the flicker immediately.
  • Page 12 AGC (Automatic Gain Control) Off/On AGC ON: The sensitivity increases automatically when light is low. AGC OFF: A-low-noise picture is obtained under a low light condition. The default setting is On. LL (Line-Lock) Off/On To select the sync mode between Internal Sync.(LL off) and Line-Lock (LL on).

  • Page 13: Simple Instructions For The Desiccant Pack

    Simple Instructions for the desiccant pack Due to the camera lens blurred from the humidity inside the camera. The desiccant pack absorb the humidity and easy instruction as following: 1. Adjust all settings first and place the desiccant pack into the gap of the machine and fix it.
  • Page 14 EverFocus Electronics Corp. Head Office: 12F, No.79 Sec. 1 Shin-Tai Wu Road, Hsi-Chih, Taipei, Taiwan TEL: +886-2-26982334 FAX: +886-2-26982380 www.everfocus.com.tw USA Office: 2445 Huntington Drive, San Marino, CA 91108, U.S.A. TEL: +1-626-844-8888 FAX: +1-626-844-8838 www.everfocus.com European Office: Albert-Einstein-Strasse 1 D-46446 Emmerich, Germany...
