EverFocus ED300 Specifications

Color Cameras
ED300
520 TVL Indoor Mini Dome Color
Features
• 520 TVL of horizontal resolution
• 1/3" Sony Super HAD CCD with approximately
410,000 pixels
• Light sensitivity of 0.4 Lux/F=1.2
• Simple Day/Night
• Video BNC test cable on camera module
• Intelligent backlight compensation
• Compact size for discreet surveillance
• Wide range automatic electronic shutter:
up to 1/100,000
• Adjustable zoom lens for desired viewing range
• Suitable for any discreet indoor application
• Available in black, white or gold base
Dimensions
13
Indoor Dome Cameras
108 mm / 4.2"

Specifications

Pickup Device 1/3" Sony Interline Transfer Super HAD CCD
Video Format NTSC or PAL
Picture Format 768 x 494 (NTSC) / 752 x 582 (PAL)
Horizontal Resolution 520 TVL
Video Output BNC 1.0 Vp-p, 75 ohm
Sensitivity 0.4 Lux/F=1.2
S/N Ratio Over 48dB (AGC Off)
Electronic Shutter 1/50 (1/60) ~ 1/100,000 sec.
Flickerless On/Off switch
Backlight Comp. On/Off switch
Auto Gain Control On/Off switch
Auto White Balance Yes
Gamma Correction 0.45
Sync. Mode Internal
Iris Level Adjustable
Lens f=3.7~12mm/F=1.2
Power Source 12VDC / 24VAC
Power Consumption 24VAC: 4.5W max. / 12VDC: 2.5W max.
Dimensions (W x H) 108 x 80 mm / 4.2" x 3.1"
Weight 0.32 kg / 0.7 lbs
Operating Temp. 0°C ~ 40°C / 32°F ~ 104°F
Humidity 20% ~ 80% humidity

Ordering Information

ED300/N: 3.7~12mm lens, Auto Iris, 520 TVL, Gold Base
ED300/NB: 3.7~12mm lens, Auto Iris, 520 TVL, Black Base
ED300/NW: 3.7~12mm lens, Auto Iris, 520 TVL, White Base
