The PRÉVOST "XL Motorcoach" Operator's
Manual has been prepared to thoroughly acquaint
you, the operator, with vehicle equipment and
features in order to fully appreciate and safely
enjoy your vehicle. Of course, you are anxious to
drive your new coach and test its features, but first
please read this publication carefully for enjoyable
and trouble free operation, while ensuring
optimum safety and passenger comfort.
book should be kept inside the vehicle at all times
for convenient reference. It is also suggested that
it remain with the vehicle at the time of resale.
Please notify PRÉVOST CAR INC. when the
vehicle's ownership is transferred so that our
records can be kept up to date. Do this by filling
out the appropriate form at the back of this
manual.
The specifications, descriptions and figures given
are based on the latest information available at
printing time. And because at PRÉVOST, we are
constantly striving to better our product, we
reserve the right to make changes at any time
without notice and/or obligation on our part.
Please note that this publication applies only to XL
Motorcoaches, manufactured by PRÉVOST CAR
INC.. It describes and explains all the equipment
and options available for installation in our factory.
Therefore, there may be equipment described
herein that is not installed on your vehicle.
XL Series Motorcoach
This Manual encompasses both XL-40 & XL-45
models; therefore, variations between them are
identified as such.
This manual, or portions thereof, cannot be
reproduced in any form whatsoever, in whole or in
part, without the written consent of PRÉVOST
CAR INC.
This
The following words are used to emphasize
particularly important information:
WARNING:
followed, could result in serious personal injury or
loss of life.
CAUTION:
followed, could cause serious damage to vehicle
components.
NOTE:
needed to fully understand and complete an
instruction.
For your own safety and to ensure prolonged
service life of your coach, heed our cautions,
warnings and notes; Ignoring them could result in
extensive damage and/or serious personal injury.
1 - 1
FOREWORD
Identifies instructions which if not
Denotes instructions which if not
Indicates supplementary information
