Air tanks draining sequence

Advertisement

Quick Links

Revision: B
APPLICATION
Model
DESCRIPTION
It is very important to drain the air tanks in the proper order to confirm the various check valves
and safety valves are functioning properly.
IMPORTANT NOTICE
This procedure provides guidelines on how to drain air tanks. However, please note
that this procedure is not a substitute for similar documents issued by your federal,
state, or provincial transportation authority.
Writer: EL
MAINTENANCE
INFORMATION
DATE:
November 2022
SUBJECT:
AIR TANKS DRAINING SEQUENCE
General update
VIN
ALL PREVOST VEHICLES
MI22-12B
SECTION: 12 BRAKE & PNEUMATIC
<QF7720955 rev 7
12-07-2022
