FOREWORD
The PRÉVOST Motorcoach Owner's Manual has
been prepared to thoroughly acquaint you, the
owner, with vehicle equipment and features in
order to fully appreciate and safely enjoy your
vehicle. Of course, you are anxious to drive your
new private motorcoach and test its features, but
first please read this publication carefully to help
ensure enjoyable and trouble free operation.
This book should be kept inside the vehicle at all
times for convenient reference. It is also
suggested that it remains with the vehicle at the
time of resale. Please notify PRÉVOST CAR
INC. when the vehicle's ownership is transferred
so that our records can be kept up to date. Do
this by filling out the appropriate form at the end
of this manual.
The specifications, descriptions and figures
given are based on the latest information
available at printing time. And because at
PRÉVOST we are constantly striving to improve
our products, we reserve the right to make
changes at any time without notice and/or
obligation on our part.
Please note that this publication applies to
factory-prepared,
conversion-ready
motorcoaches, manufactured by PRÉVOST
CAR INC. It describes and explains the
equipment and options available for installation
in
our
factory. Therefore, there may be
equipment described herein that is not installed
on your vehicle. This publication also does not
cover equipment installed by your interior
designer or system manufacturer.
This manual, or portions thereof, cannot be
reproduced in any form whatsoever, in whole or
in part, without the written consent of PRÉVOST
CAR INC.
The following words are used to emphasize
particularly important information:
Warning :
followed, could result in serious personal injury
or loss of life.
Caution :
followed, could cause serious damage to vehicle
components.
Note :
needed to fully understand and complete an
instruction.
For your own safety and to ensure prolonged
service life of your private motorcoach, heed our
cautions, warnings and notes. Ignoring them
could result in extensive damage and/or serious
personal injury.
Caution :
inside vehicle, make sure to cut electrical power
and air supply. A component could be supplied
with electricity even if battery master switch is
set to the OFF position and/or a component
luxury
could be pressurized even if air tanks are
emptied. Always refer to the appropriate wiring
and pneumatic diagrams prior to working on
electrical and/or pneumatic systems.
Prior to welding or soldering on the vehicle,
disconnect all electronic modules. If these
modules
disconnected, electronic components (EPROM,
CHIPS) could be permanently damaged.
Refer to your maintenance manual for all related
procedures.
iv
Identifies instructions which, if not
Denotes instructions which, if not
Indicates supplementary information
Prior to working on a system
(ECM,
ECU,
ABS)
are
not
