Rae MultiRAE Plus Using Manual

Personal multigas monitor
Hide thumbs

Advertisement

Quick Links

Download this manual
MultiRAE Plus
Using the
MultiRAE Plus
personal multigas
monitor
Firmware v 3.12B

Advertisement

loading
Need help?

Need help?

Do you have a question about the MultiRAE Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rae MultiRAE Plus

Summary of Contents for Rae MultiRAE Plus

  • Page 1 MultiRAE Plus Using the MultiRAE Plus personal multigas monitor Firmware v 3.12B...
  • Page 2 Training Agenda • MultiRAE Plus features • Turning on the MultiRAE Plus • Recommended Daily Start-up Procedure • User displays • Alarm modes • Programming displays • Calibration...
  • Page 3 MultiRAE Plus Features: Sensors • Oxygen: 0-30% • Combustibles: 0-100% of LEL • Toxic sensors: select two from CO, S, SO , NO, NO , Cl , HCN, NH • VOC monitor: 0-2000 PPM...
  • Page 4 MultiRAE Plus Features: Easy Sensor Access • New innovative casing design • Easy access to sensors with penny, nickel, or dime...
  • Page 5 MultiRAE Plus Features: Reliability • Extremely rugged for extensive field use • Weather proof case ° ° ° ° • -4 F to 113 F (-20 C to 45 • 4-way power: Li-Ion(NiCad), alkaline or run continuously on 110 VAC and 12 VDC •...
  • Page 6 MultiRAE Plus Features: Rugged Case Buzzer & Exhaust Display Charger Serial Port Port...
  • Page 7 MultiRAE Plus Features: Simple Faceplate Light Alarm LEDs Sensor • Three buttons on a sealed membrane faceplate: – Y/+ (horn): clears & tests alarms – N/- (light): turns on manual backlight for 90 seconds – MODE (ON)
  • Page 8 MultiRAE Plus Features: Rugged Boot Rugged Rubber External Filter Boot Belt Clip...
  • Page 9 • External filter for added protection • Pump stall feature: when moisture is detected or when pump is blocked the pump will shut off, protecting the MultiRAE Plus from potential damage • ~150cc/min at low flow, ~250cc/min at high flow...
  • Page 10 MultiRAE Plus Features: External Filter • Always use the external filter • Replace when it looks very dirty • Replace when MultiRAE Plus is in pump alarm with the filter on and you can clear the pump alarm with the filter off.
  • Page 11 MultiRAE Plus Start-up: Turning On • Unplug MultiRAE Plus from charger • Hold “MODE” Key to turn on • Alarm will beep once • Watch display screen for messages such – Sensors installed & their warranty expiration – Alarm limits –...
  • Page 12 MultiRAE Plus Start-up: Warnings TOX1 TOX2 Incorrect Year Check Clock!!! • If this screen appears during the start-up just acknowledge it with the “Y” key and follow the procedure for setting the clock. • The battery has gone dead and the MultiRAE...
  • Page 13 • This is a warning screen. As long as the sensor calibrates properly it is valid to continue using it. Acknowledge by pressing the “Y” key to continue warm-up. • For maximum MultiRAE Plus availability, RAE Systems recommends replacing sensors at the end of their warranty period...
  • Page 14 MultiRAE Plus Start-up: Fresh Air Calibration TOX1 TOX2 Fresh air calibration? • After 90 sec. warm-up, the MultiRAE Plus will ask to perform a fresh air calibration • If you are in clean, ambient air, press • The sensors will be zeroed...
  • Page 15 MultiRAE Plus Start-up: Check Sensor Zero TOX1 TOX2 20.9 • If there is no alarm, and the sensor readings are in the range shown above, then the MultiRAE Plus is ready for use.
  • Page 16 MultiRAE Plus Start-up: Check Sensor Zero TOX1 TOX2 20.6-21.2 • If any reading is outside these limits, wait a few minutes then check again. – If readings are in limits use the unit – If readings are still outside these limits...
  • Page 17 “Lamp” display along with audible alarm indicates that PID lamp has failed to light • Press “Y/+” key to clear alarm, if it clears MultiRAE Plus is ready for use • If alarm does not clear, wait a few minutes and check again...
  • Page 18 TOX1 TOX2 Lamp 20.9 • If after a few minutes the “Lamp” message remains, turn off MultiRAE Plus and restart • If after restart “Lamp” message disappears, MultiRAE Plus is ready for use • If after restart “Lamp” message remains, the...
  • Page 19 MultiRAE Plus Start-up: Pump Alarm TOX1 TOX2 Pump 20.9 • Every time the MultiRAE Plus is used it is important to check pump flow • Block the filter on the pump inlet • Reset pump alarm by pressing the “Y” key •...
  • Page 20 3 Display Modes • Text Mode: 3 screens and has password to get into programming (default mode) • Display Mode: 7 screens and has password to get into programming • Advanced Mode: 11 screens for most advanced users...
  • Page 21 Comparison of Display Modes Advanced Display Text Sensor ID Sensor ID Sensor ID w/OK PEAK PEAK Battery PC Comm STEL STEL Battery Battery Time/Date/Temp/Time PC Comm unit has been on Start Datalog* * Will not show LEL Gas if no datalogging VOC Gas option or auto PC Comm...
  • Page 22 Instantaneous Reading (Main Display) TOX1 TOX2 20.9 • This screen alternates between the instantaneous reading and the sensor name approximately every 3 seconds...
  • Page 23 Instantaneous Reading (Main Display) TOX1 TOX2 • CO: Carbon Monoxide Sensor • VOC: Photoionization Detector (PID) • S: Hydrogen Sulfide Sensor • LEL: Combustible gas sensor • OXY: Oxygen sensor • Tap “MODE” key to proceed...
  • Page 24 This screen is deleted in Text Mode TOX1 TOX2 PEAK 20.9 • Holds Highest reading since MultiRAE Plus was turned on • Press “Y” key to clear peak/min – Screen will prompt: “Are you sure?” – Press “Y” to confirm peak clearing...
  • Page 25 Minimum Reading Display This screen is deleted in Text Mode TOX1 TOX2 13.5 • Holds Lowest reading since MultiRAE Plus was turned on • Tap “MODE” key to proceed to next screen...
  • Page 26 STEL • Short Term Exposure Limit (average for the past 15 minutes) • Displays “***” until MultiRAE Plus has been on for 15 minutes • STEL only is calculated for VOC & toxics • STEL alarm beeps once a second •...
  • Page 27 TOX1 TOX2 • Time Weighted Average is the accumulated reading of gas concentration divided by 8 hours since the MultiRAE Plus was turned on • TWA only is calculated for VOC & toxics • TWA alarm beeps once per second •...
  • Page 28 This screen is deleted in Text Mode TOX1 TOX2 Battery = 5.1V Shut off at 4.1V • MultiRAE Plus shuts down when battery voltage drops below 4.2 volts • Normal Full Charge is over 4.8 volts • Tap “MODE” key to proceed to next screen...
  • Page 29 Feb 15, 01 12:00 ON=01:22 • Date, Time of day • Accumulated time in hours and minutes since the MultiRAE Plus was turned on • Internal Temperature in Centigrade or Fahrenheit (operating range from -20-45 C, - 4-113 • Tap “MODE” key to proceed...
  • Page 30 This screen is deleted in Display & Text Mode TOX1 TOX2 Start Datalog? • Automatic: this screen is deleted and it logs data as soon as the MultiRAE Plus on (monitors with Datalogging ship in Automatic Datalog Mode) • Manual: logs if “Y/+” key is pushed now •...
  • Page 31 TOX2 20.9 • A small “L” is displayed in the left center of the MultiRAE Plus screen indicates datalogging • Will datalog 20,000 points (80 hrs, 5 channels, 1 min interval) • User can choose one of 4 datalog modes (Manual, Automatic, Periodic &...
  • Page 32 LEL Units Display This screen is deleted in Display & Text Mode TOX1 TOX2 LEL gas = Methane • Target Gas for LEL displayed here (MultiRAE Plus is currently measuring LEL in units of methane) • Correction Factor can only be changed in programming mode •...
  • Page 33 VOC Units Display This screen is deleted in Display & Text Mode TOX1 TOX2 VOC gas = Isobutylene • Target Gas VOC is displayed here (MultiRAE Plus is currently measuring VOC in units of isobutylene) • Correction Factor can only be changed in programming mode •...

  • Page 34: Communicate With Pc

    TOX1 TOX2 Communicate with PC? • If “Y/+” key is pushed then MultiRAE Plus will display “Monitor will Pause. OK?” • If “Y/+” key is pushed again the MultiRAE Plus will display “Ready...” until it receives a signal from the computer or the “MODE”...
  • Page 35 Communicate with PC Display TOX1 TOX2 Ready... • When the MultiRAE Plus is in this communication standby mode it stops monitoring gas concentrations and stops datalogging. • Datalogging must be manually restarted when exiting unless automatic datalogging is in use.
  • Page 36 • The MultiRAE Plus will provide audible and visual alarms to alert users to unsafe states • The MultiRAE Plus also has the ability to run silent, with audible alarms turned off • It is extremely important to note that during...
  • Page 37 MultiRAE Plus Alarms: High TOX1 TOX2 High 20.9 • “High” display along with 3 beat/second audible/visible alarm and flashing display backlight indicates that VOC sensor (PID) has exceeded high alarm setpoint (100 ppm VOC default). • Press “Y/+” key to clear if latching alarm...
  • Page 38 MultiRAE Plus Alarms: Low TOX1 TOX2 • “Low” display along with 2 beat/second audible/visual alarm and flashing display backlight indicates that Oxygen sensor has gone into low alarm (less than 19.5% Oxygen default) • Press “Y/+” key to clear if latching alarm...
  • Page 39 “STEL” display along with a 1 beat/second audible/visual alarm indicates indicates that VOC sensor has exceeded STEL alarm setpoint (25 ppm VOC default) • This alarm will only clear after 15 minutes in clean air or the MultiRAE Plus is turned off!
  • Page 40 MultiRAE Plus Alarms: TWA TOX1 TOX2 20.9 • “TWA” display along with a 1 beat/second audible/visual alarm indicates indicates that VOC sensor has exceeded the TWA alarm setpoint (10 ppm VOC default) • This alarm will only clear after moving...
  • Page 41 Alarms: LEL OFF TOX1 TOX2 20.9 • “OFF” display along with a 3 beat/second audible/visual alarm indicates that LEL sensor has been exposed to too much gas and has shut off to protect the sensor. • Move the meter to clean air and press the “Y”...
  • Page 42 Alarms: NEG TOX1 TOX2 20.9 • “NEG” display along with a 1 beat/second audible/visual alarm indicates indicates that VOC sensor has drifted negative (below zero) because the sensor was zeroed in an area containing VOCs. • Perform “Fresh Air Calibration” in an area clear of all VOCs.
  • Page 43 MultiRAE Plus Alarms: Pump TOX1 TOX2 Pump 20.9 • “Pump” display along with 3 beep audible alarm indicates that pump has stopped due to line clog • Pump alarm is a latching alarm • Clear line/filter and press “Y/+” key to clear...
  • Page 44 A flashing “Bat” display along with a 1 beep alarm every 10 seconds indicates that the battery voltage has dropped below 4.35 V and it will shut down in 20-30 minutes • Quickly complete confined space entry and charge MultiRAE Plus or install alkaline battery...
  • Page 45 MultiRAE Plus Alarms: Memory Full TOX1 TOX2 MEM 20.9 • A flashing “MEM” display along with a 1 beat/second audible/tactile/visual alarm indicates that the datalog memory is full. • Clear datalog in “View or Change Datalog?” • If you get this alarm you might want to consider changing “Select memory full type?”...
  • Page 46 • Hold “MODE” and “N/-” keys for 5 sec. to get in Programming Mode – Default password is 0000 • If MultiRAE Plus asks a question “?” – Answer “Y” or “N” • To Accept or Escape – Use “MODE” Key –...
  • Page 47 Programming Menus • Calibrate Monitor? • Change Alarm Limits? • Change Datalog? • Change Monitor Setup? • Change Sensor Configuration? Choose (Y/+) to accept or (N/-) to move on...
  • Page 48 Calibrate Monitor? • Fresh Air Calibration? – Make sure air is clean! • Multiple Sensor Calibration? • Single Sensor Calibration? • Modify Span Gas Value? • Change LEL/VOC Span Gas? – Choose (Y) to accept or (N) to move on, MODE to escape...
  • Page 49 Multiple Sensor Calibration TOX1 TOX2 - - - - - - • At “Multiple Sensor Calibration” press “Y/+” • For CO/H S/LEL mixed gas calibration the next screen should appear as above...
  • Page 50 Multiple Sensor Calibration TOX1 TOX2 Apply Mixed Gas • press “Y/+” key to display this screen • Attach calibration gas regulator to mixed gas cylinder • Turn on calibration gas • Attach calibration hose to MultiRAE Plus • Follow instructions on screen...
  • Page 51 Multiple Sensor Calibration TOX1 TOX2 No Gas Flow... • If you get this screen check for gas flow, the MultiRAE Plus will not perform span calibrations unless it senses calibration gas...
  • Page 52 Multiple Sensor Calibration TOX1 TOX2 Apply gas or hit any key to start • Try again after you have verified that the gas is correct and it is flowing properly • Follow instructions on screen • Disconnect regulator from gas cylinder when complete calibration...
  • Page 53 Single Sensor Calibration TOX1 TOX2 pick • VOC can only be calibrated individually, other sensors can be calibrated individually if necessary • At “Single Sensor Calibration” press “Y/+” • Use “MODE” to select VOC...
  • Page 54 Single Sensor Calibration • Attach calibration gas regulator to VOC (Isobutylene) cylinder • Turn on calibration gas • Attach calibration hose to MultiRAE Plus and make sure it is tight • With cursor on VOC press “Y/+” key • Follow instructions on screen •...
  • Page 55 • Modify Span Value – Allows you to change the calibration gas values to use other cal gases – Do not change if you are using the RAE Systems cal gas supplied with your meter • Change LEL/VOC Span Gas? –...
  • Page 56 Change Alarm Limits? • Change High alarm limit? – 3 Beeps per second (“High”) • Change Low alarm limit? – 2 Beeps per second (“Low”) • Change STEL alarm limit? – 1 Beep per second (“STEL”) • Change TWA alarm limit? –...
  • Page 57 Change Datalog? • Clear All Data? • Change Datalog Period? • Select Data Type? • Enable/Disable Datalog? • Select memory full type? Choose (Y/+) to accept or (N/-) to move on, MODE to escape...
  • Page 58 Select Memory Full Type? • Wrap around (default): after the memory becomes full the newest data is written over the oldest data (First in First Out or FIFO). – This is an excellent feature to provide “background” datalogging that is only used in case of an incident.
  • Page 59 Change Monitor Setup? • Change Site ID? • Change ID Mode? – If enabled the MultiRAE Plus will pause on start-up until correct ID is entered • Change User ID? • Change Alarm Mode? • Change User Mode? – “Advanced”...
  • Page 60 Change Monitor Setup? • Change Real Time Clock? • Change Backlight Mode? • Change Password? • Change Pump Speed? • Change Averaging Method? • Change Display Language? (English, Spanish) • Set Temperature Unit? (C or F Choose (Y) to accept or (N) to move on MODE to escape...
  • Page 61 Change Sensor Configuration? • Change LEL/VOC Gas Selection? • Enable/Disable Sensor? • Change Dilution Ratio? • Change PID Lamp Type? Choose (Y) to accept or (N) to move on, MODE to escape...
  • Page 62 MultiRAE Plus: Power Off • Hold Mode Key for full 5 seconds • Audible alarm will beep and display will read “Power-down in ...5 seconds” • Plug 12 VDC charger into MultiRAE Plus charge port when not in use...
  • Page 63 MultiRAE Plus: Smart Charging TOX1 TOX2 Charging..• Li-Ion batteries jump right to this screen • Nicad batteries will ask for “Deep Discharge” which is recommended about once a month, Li-ion don’t need discharge • Full charge can take up to 8 hours...
  • Page 64 MultiRAE Plus: Trickle Charging TOX1 TOX2 Fully Charged <Li-Ion> • When fully charged it will switch to trickle charge to maintain the battery • Turning off and on power to charger will reset charge to high and may burn-out battery if done repeatedly...
  • Page 65 • Provides 12-14 hours of duration • Make sure that cable runs in groove between batteries or it won’t fit • When reattaching MultiRAE Plus lid, seat it first at back by batteries then push the front down (silver MultiRAE Plus units only)
