Philco PFL510CLFW3CF Manual

MODEL:PFL510CLFW3CF - PFL812LFW3CF
PRINCIPAL FUNCTIONS OF THE WASHING MACHINE
USE OF THE WASHING MACHINE
The electronic washing machine is equipped with an "EASY LOGIC" system that recognises the
quantity of clothes put in, consequently adjusting the quantity of water to be used and reducing
the washing time proportionally. The result is a saving in water, time and energy. In the case in
which the quantity of clothes to be washed is less than the maximum recommended load (see
technical specifications table), the quantity of water used for the wash will be reduced by 2 litres
for each kg less of laundry. In the case of washes that are half load or less, the machine will
automatically perform one rinse less than programmed. N.B. The "EASY LOGIC" function only
works on the cotton programs.
WASHING CYCLE:
(If this sequence of operations is followed, the washing machine will carry out the
washing cycle that is set)
1. Open the door.
2. Load the laundry into the drum and carefully close the door.
Warning: You must not overload the washing machine. It is not recommended to wash
articles that absorb a large amount of water, for example carpets.
3. Pour the low-suds washing powder and the fabric conditioner for automatic washing machines
into their respective compartments (see the "USE OF DETERGENTS" chapter)
4. Close the detergent compartments, making sure that they are not removed while the washing
machine is running, because the water could come out.
5. Turn the program selector knob (P) choosing the desired program and temperature to match the
type of fabric to be washed (see: PROGRAM TABLES").
N.B. When the knob is set, the duration of the chosen cycle in minutes appears on the
display. During the cycle the time shown decreases until 'END' appears, indicating the
end of the program.
6. Choose the desired spin speed pressing button (H) (see "VARIABLE SPIN").
7. Select the buttons (C) with the functions to be used (see "OPTIONAL FUNCTIONS").
the time shown on the display will vary according to the functions that are set.
8. Press button (I) if required (see "DELAYED START").
9. Press button (L) to start the washing cycle (see "START BUTTON").
10. At the end of the wash, turn the program selector knob (P) to "STOP".
11. With dr y hands, remove the washing machine plug from the mains socket.
12. Open the door and remove the laundry.
13. Close the water supply tap.
P B A
I H C L
"EASY LOGIC" "EASY LOGIC" TECHNOLOGY TECHNOLOGY
SM2280
A LED Start
B Display
C Optional functions button
H Spin selection button
L Start button
I Delayed Start button
P Program and temperature knob
1
GB
