Summary of Contents for Drive DeVilbiss Healthcare XSAWCSP18BLST
- Page 1 XS Aluminium Wheelchair (XSAWCSP18BLST, XSAWCSP20REDST, XSAWCTS18BLST, XSAWCTS20REDST) Instructions for use...
-
Page 2: Parts Description
12.5" WHEEL 24" WHEEL & HANDRIM PARKING BRAKE LEVER FOOTREST FOOT FRONT REST CASTOR FRONT STEPPER TUBE CASTOR Self Propel models Transit models 18” (XSAWCSP18BLST) 18” (XSAWCTS18BLST) 20” (XSAWCSP20REDST) 20” (XSAWCTS20REDST) XS Aluminium Wheelchair (2021-02 rev1) Page 2 of 12... - Page 3 preparing for use symbols These instructions should be read carefully before using the wheelchair. This product does not have a service manual. The following parts should be adjusted by a healthcare professional to suit each user’s requirements: Rear Wheels Use the axle bracket to alter the horizontal position of the rear wheels on the transit models.
-
Page 4: Footrest Adjustment
footrest adjustment To fit the footrests, align approximately 45º outwards, push down firmly into the frame (1) then rotate inwards (2) until they lock into place. Pull the handle / lever and rotate to release. For optimum comfort it is important to attain the correct leg position. - Page 5 transfer and use Before using the wheelchair, read the safety notices below; • Do not exceed the 10º maximum gradient. Use slow speeds and do not reverse down a gradient. • Do not use on escalators. • The wheelchair is only suitable for single occupancy. •...
- Page 6 steep terrain, kerbs and steps Steep terrain: These wheelchairs are not designed for use on gradients beyond 10°. When on a slope, avoid swerving or sudden changes in movement. Over kerbs: Attendants push down on the stepper tube with a foot to raise the front castors (when mounting a kerb for example).
-
Page 7: Brake Operation
brake operation Parking Brakes To apply the parking brakes, push the handle on the brake unit until locked in place. To release the brake, pull the handle in the opposite direction. The brakes should always be applied when the wheelchair is stationary. Cable Brakes Operating On the transit models, the attendant... -
Page 8: Disassembly And Storage
disassembly and storage This wheelchair has a number of quick release components and the wheelchair frame is easily foldable. This facilitates a light carry weight and minimises storage space required. To disassemble for storage, transport or maintenance, follow the steps below. To reassemble components, reverse these instructions. -
Page 9: Care And Maintenance
Do not use a damaged or badly worn wheelchair. Users should routinely check for any malfunctions or changes in performance. See Accessories and Spare Parts section for approved parts available from Drive DeVilbiss Healthcare Ltd. • Before each use of the wheelchair, the brakes and tyres should be checked. It can be folded up for storage, with the parking brakes on. -
Page 10: Specification
Model XSAWCSP18BLST XSAWCSP20REDST XSAWCTS18BLST XSAWCTS20REDST Maximum 115 kg 115 kg 115 kg 115 kg occupant mass Overall length 103 cm 103 cm 92 cm 92 cm with legrest Overall width 63 cm 63 cm 63 cm 63 cm Folded length... -
Page 11: Warranty
If you have any queries or require full warranty conditions, please contact your provider. accessories and spare parts Drive DeVilbiss Healthcare Ltd provide accessories for wheelchairs in the XSAWC range. Spare parts are also available for maintaining your wheelchair. To order these parts, contact your provider. Visit www.drivedevilbiss.co.uk to find your local stockist. - Page 12 Koningin Julianaplein 10, le Verd, 2595AA, The Hague, NL Drive DeVilbiss Healthcare Ltd Sidhil Business Park, Holmfield, Halifax West Yorkshire, HX2 9TN, GB Drive DeVilbiss Healthcare Ltd provide these instructions for use and product markings. info@drivedevilbiss.co.uk www.drivedevilbiss.co.uk Service & Maintenance...
