WAN Status

Use the WAN Status link on the main menu to view this screen.
Data – System Status
NAT This section displays data for each WAN port.
Statistics
•
•
•
•
•
•
Interface This section displays cumulative statistics.
Statistics
Use the "Restart Counter" button to restart these counters when required.
Figure 9-3: WAN Status
Connection status – This will display either Connected or Not Connected.
Default Loading Share - The default traffic loading between the WAN ports.
Current Loading Share – The current traffic loading between the WAN ports.
Current Loading – The number of sessions, Bytes and Packets currently
being processed on each port.
Current Bandwidth – The current Download and Upload speeds on each
WAN port.
"Check NAT Detail" will display the NAT Status screen, described below.
Page 66
