Note:
If there is an entry or entries in the Routing table with an Index of zero (0), these are System entries.
You cannot modify or delete these entries.
Settings – Routing
•
Dynamic
Routing
•
•
Entry Index
•
•
•
Network The network address of the remote LAN segment. For standard class "C" LANs,
the network address is the first 3 fields of the Destination IP Address. The 4th
Address
(last) field can be left at 0.
Netmask The Network Mask for the remote LAN segment. For class "C" networks, the
default mask is 255.255.255.0
Figure 8-1: Routing
RIP v2 – This acts as "master" switch. If enabled, the selected WAN or LAN
will run RIPv1/v2, otherwise they don't have RIP function.
LAN, WAN1, WAN2 – If enabled, any WAN or LAN can execute RIP function.
If adding a new entry, ignore this field.
To edit an existing entry, select it from the list, and click the "Select" button.
The screen will then update with the data for the selected entry.
If the Index is 0, this is a System entry that you can neither delete nor modify.
Page 60
