- Page 1 GS-5208PLG V2 Quick Installation Guide 05-2021 / v1.0...
-
Page 2: Table Of Contents
Contents I. Product Information ..........1 I-1. Package Content ..............2 I-2. Hardware Overview ............. 2 I-3. LED Status................3 II. Installation .............. 4 II-1. Mounting the Switch ............4 II-1-1. Placement Tips ............4 II-1-2. Rack Mounting ............5 III. -
Page 3: Product Information
I. Product Information The Edimax Pro GS-5208PLG V2 is a web-smart switch with 8 Gigabit PoE+ and 2 Gigabit SFP slots. Designed for medium to small network environments, its standard 19-inch 1U rack-mount brackets allow for integration with the most widely used mounting systems on the market. -
Page 4: Package Content
I-1. Package Content Before start using this product, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s): GS-5208PLG V2 Power Cord Rack-Mount Kit & Screws I-2. Hardware Overview Descriptions LED (PoE Alert, PWR) Reset Button LED (PoE) LED (Link/Act) -
Page 5: Led Status
I-3. LED Status Function Status Description On (Green) Power on Power off Blinking System boot up Total PoE power consumed is under PoE On (Green) power budget PoE Alert Total PoE power consumed is under PoE power budget On (Green) Link at 1000M Blinking (Green) Sending or receiving data... -
Page 6: Installation
II. Installation This chapter describes how to install and connect your Edimax Switch. Read the following topics and perform the procedures in the correct order. Incorrect installation may cause damage to the product. II-1. Mounting the Switch There are two ways to physically set up the switch. -
Page 7: Ii-1-2. Rack Mounting
II-1-2. Rack Mounting You can mount the switch in any standard size, 19-inch (about 48 cm) wide rack. The switch requires 1 Rack Unit (1U) of space, which is 1.75 inches (44.45 mm) high. For stability, load the rack from the bottom to the top, with the heaviest devices on the bottom. - Page 8 Secure the switch on the equipment rack with the screws provided. Figure 6 - Rack Installation...
-
Page 9: Getting Started
III. Getting Started This section provides an introduction to the web-based configuration utility, and covers the following topics: Powering on the device Connecting to the network Power over Ethernet (PoE) considerations Starting the web-based configuration utility III-1. -
Page 10: Iii-2. Connecting To Network
III-2. Connecting to Network To connect the switch to the network: Connect an Ethernet cable to the Ethernet port of a computer Connect the other end of the Ethernet cable to Port 1-8 of the switch. The LED of the port lights if the device connected is active. Connect the switch to end nodes using a standard Cat5e Ethernet cable to connect the switch to end nodes as shown in the illustration below. - Page 11 Launching the Configuration Utility To open the web-based configuration utility: Open a Web browser. Enter the IP address of the device you are configuring in the address bar on the browser (factory default IP address is 192.168.2.1) and then press Enter. The default username is “admin”...
- Page 12 COPYRIGHT Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co., Ltd.
- Page 13 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 14 EU Declaration of Conformity English: This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EU. Français: Cet équipement est conforme aux exigences essentielles et autres dispositions de la directive 2014/30/EU. Čeština: Toto zařízení je v souladu se základními požadavky a ostatními příslušnými ustanoveními směrnic 2014/30/EU.
- Page 15 Declaration of Conformity We, Edimax Technology Co., Ltd., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directives. Equipment: 8-Port Gigabit, 8-Port Long range PoE Switch Model No.: GS-5208PLG V2 The following European standards for essential requirements have been followed:...
