Lab-Volt 8096 Manual page 33

Model 9630 – Analog/Digital Signal Combiner
Analog Inputs (2)
Analog Outputs 3 and 4
Analog Outputs 5 and 6
Test Points
Physical Characteristics
Model 9631 – Data Acquisition Interface
Analog Inputs (2)
Digital Inputs (2)
Parallel Digital Input
Test Points
Physical Characteristics
Model 9632 – Analog/Digital Output Interface
Analog Outputs (4)
Digital Outputs (4)
Test Points
Physical Characteristics
Model 9633 – Radar Target Tracking Interface
RF Inputs and Outputs
Lobe Switch Control Input
Lobe Switch Control Output
Antenna Rotation Command Input
Antenna Rotation Command Output
Test Points
Physical Characteristics
Model 9694 – Hand Controller
Physical Characteristics
Voltage Range -10 to +10 V
Impedance 10 kΩ
Voltage Range -1 to +1 V
Impedance 600 Ω
Voltage Range -11 to +11 V
Impedance 600 Ω
6
Dimensions (H x W x D) 114 x 110 x 209 mm (4.5 x 4.3 x 8.2 in)
Net Weight 0.6 kg (1.4 lb)
Voltage Range -1.5 to +1.5 V
Impedance 10 kΩ
TTL
TTL, 10 bits
4
Dimensions (H x W x D) 114 x 110 x 209 mm (4.5 x 4.3 x 8.2 in)
Net Weight 0.6 kg (1.4 lb)
Voltage Range -10 to +10 V
Impedance 600 Ω
TTL
8
Dimensions (H x W x D) 114 x 110 x 209 mm (4.5 x 4.3 x 8.2 in)
Net Weight 0.6 kg (1.4 lb)
Impedance 50 Ω
Frequency Range 8 to 10 GHz
Voltage Range -5 to +5 V
Impedance 1.5 kΩ
Voltage Range -5 to +5 V
Impedance 1.0 kΩ
Voltage Range -10 to +10 V
Impedance 10 kΩ
Voltage Range -10 to +10 V
Impedance 600 Ω
4
Dimensions (H x W x D) 114 x 110 x 209 mm (4.5 x 4.3 x 8.2 in)
Net Weight 0.7 kg (1.6 lb)
Dimensions (H x W x D) 190 x 165 x 165 mm (7.5 x 6.5 x 6.5 in)
Net Weight 0.8 kg (1.8 lb)
33
