Model 9608 – Radar Jamming Pod Trainer (cont'd)
Signal Repeater (Programmable Delay Line) Maximum Input Power
Physical Characteristics
Model 9609 – Power Supply
Power Requirement
Unregulated DC Outputs
Line Input Protection
Unregulated DC Output Protection
Physical Characteristics
Model 9610 – RCS/ISAR Measurement Interface
Frequency Range
RF Amplifier
Limiters
RF Input and Output Impedance
Sync. Input
Physical Characteristics
Model 9611 – RCS/ISAR Processor
A/D Converters
Averaging
Physical Characteristics
Model 9612 – Phased Array Antenna
Scan Width
Number of Beams
Horizontal Beam Width
Gain
RF Input and Output Impedance
Control Input
Physical Characteristics
Model 9613 – Phased Array Antenna Controller
Scan Mode
Scan Speed (Continuous Scan Mode)
Beam Sequence
Range of Delay
RGPO Walk-Off Time
Dimensions (H x W x D)
Net Weight
Current
Dimensions (H x W x D)
Net Weight
Maximum Gain
On Time per Pulse
Type
Voltage Limits
Dimensions (H x W x D)
Net Weight
Resolution
Dynamic Range
Approx. Dimensions (H x W x D)
Approx. Net Weight
Dimensions (H x W x D)
Net Weight
+10 dBm
2.66 to 5.60 ns (40 to 84.2 cm), adjustable in 7 steps of 0.42 ns
(6.3 cm)
Selectable, 0.8, 1.6, 4.0, and 8.0 s
150 x 170 x 440 mm (5.9 x 6.7 x 17.3 in)
3.4 kg (7.5 lb)
120 V – 50/60 Hz 220 V – 50 Hz
1.5 A
!25 V typ. !1.5 A max.; +11 V typ. !3 A max.; +25 V typ.
!1.5 A max.
2-A / 1-A circuit breaker
1.5-A and 3-A circuit breakers
112 x 330 x 300 mm (4.4 x 13 x 11.8 in)
6.7 kg (14.8 lb)
8 to 10 GHz
22 dB
~150 ns
Diodes
±1 V
50 Ω
TTL
112 x 330 x 300 mm (4.4 x 13.0 x 11.8 in)
3.2 kg (7.1 lb)
10 bits
54 dB
Selectable, 4, 8, 16, and 32 samples
400 x 200 x 450 mm (16 x 8 x 18 in)
13.6 kg (30 lb)
±35E
16
5 to 6E
20 to 22 dBi
50 Ω
TTL
450 x 370 x 490 mm (17.7 x 14.6 x 19.3 in)
7.5 kg (16.5 lb)
Manual, Continuous, and PRF Locked
Selectable, 54, 90, 135, 270, 540, 810, and 1080 scans/min
Incremental, Pseudo-Random, and Even
240 V – 50 Hz
0.75 A
